Specifications
1310/1550nm 37/35dB
Minimum Event Dead Zone < 0.8m
capable of finding 2m jumper
one-button operation
Save up to 5000 traces
AE3000 series Optical Time Domain Reflectometer(OTDR)
Description
AE3000 Series Handheld OTDR is a high performance, multi-purposes handheld OTDR. The visual fault location (VFL) could assist OTDR locate the fault much quicker. AE3000 is the ideal OTDR solution for both installation and maintenance services.
Key Features
- High Accuracy : Minimum Event Dead Zone < 0.8m, capable of finding 2m jumper.
- Fast Operation : Minimum measurement time can be set to 5s and it only takes 30s to measure a fiber which is 100km or longer
- Handy Operation : Result analysis can be completed by one-button operation
- Cost Effective : The lowest price with same dynamic range level among all competitive products
Optical Network Test Solution
AE3000 series OTDR is a high performance and multi-purposes portable OTDR. Comparing to the traditional OTDR, AE3000 is designed with new circuit design and exterior design which makes it much lighter of weight and higher performance.
ParameterSetup
AE3000 offers user friendly interface which is similar to Windows interface style. It is very easy to pick up the way of usage without professional training. AE3000 also offers online helps which answer most of the frequently asked questions.
Auto Diagnosis and Auto Correction
Optical adapter detection and protection
AE3000 triggers the alarm when light injection has been found at the optical adapter.
Optical adapter connection detection
Warning is provided if optical adapter is stained in order to avoid influencing the test result.
Self calibration and correction
Auto calibration function could self calibrate the instrument after using a certain period of time.
Specification
Parameters | |
Distance |
3m ~ 200km |
Pulse Width |
AE3000A/AE3000B: 5ns ~ 20μs |
Measurement Time |
User-defined |
Distance Uncertainty |
±(1m +0.0005% × distance + sampling resolution) |
Loss Resolution |
0.001dB |
Distance Resolution |
0.05m |
Linearity |
0.04dB/dB |
Sampling Points |
128000 |
Data Storage |
>5000 |
Others |
|
Display |
6.4’’ TFT LCD |
Optical Adapter |
FC/PC, SC/PC |
Interface |
USB (Principle and subordinate each), SD, RJ45 |
Battery |
Rechargeable Lithium battery, charging < 4 hours, Operation time > 10 hours |
Power Supply |
AC/DC Adapter, Input AC90-240V ±10% Output 12V |
Operating Temperature |
-10°C ~ 50°C |
Storage Temperature |
-40°C ~ 85°C |
Relative Humidity |
< 80% |
Weight |
< 2kg |
Dimension |
248 x 201 x 75 (mm) |
Accessory | |
SC/PC Adapter |
1 |
AC Adapter |
1 |
Quick Operating Guide |
1 |
Package Bag |
1 |
Disc |
Toolbox Software and User Manual |
