Help CenterNEW Deviser AE2300 1310/1550nm 34/32dB Handheld OTDR
Related Products
-
AE3000 Series Optical Time Domain Reflectometer(OTDR)US$ 1 - 2MOQ: 1 Piece -
NEW Deviser SA8300A 9kHz~3GHz Portable Spectrum AnalyzerUS$ 1 - 2MOQ: 1 Piece
-
NEW Deviser EP700 Optical MultimeterUS$ 1 - 2MOQ: 1 Piece
-
NEW Deviser DS2002/2003 Handheld Signal Level MeterUS$ 130 - 250MOQ: 1 Piece
-
Deviser TC500 Ethernet Cabling Tester Ethernet Test MeterUS$ 1 - 2MOQ: 1 Piece
Specifications
Dynamic Range 34/32dB
Minimum Event Dead Zone < 1.5m
Operating Hour > 8 hrs
One-Button operation
Performance to Price Ratio
Description
AE2300 Series Handheld OTDR is a high performance, multi-purposes handheld OTDR. The visual fault location (VFL) could assist OTDR locate the fault much quicker. AE2300 is the ideal OTDR solution for both installation and maintenance services.
|
Model Wavelength (nm) Dynamic Range Event DZ (m) Attenuation DZ (dB) (m) | ||||
AE2300L |
1310/1550 |
32/30 |
3 |
<15 |
AE2300 |
1310/1550 |
34/32 |
1.5 |
<8 |
AE2300H |
1310/1550 |
36/34 |
0.8 |
<5 |
AE2300P-1 |
1310/1550/1625 |
36/35/35 |
0.8 |
<5 |
AE2300P-2 |
1310/1550/1650 |
36/35/35 |
0.8 |
<5 |
AE2300P-3 |
1310/1550/1490 |
36/35/35 |
0.8 |
<5 |
Key Features
- High Accuracy : Minimum Dead Zone < 0.8m
- Fast Measurement : Minimum measurement time could be set to 5 seconds, and within 30 seconds a 100km fiber can be measured .
- Handy Operation : One-Button operation allows test result analysis completion in one step which detect and display the fault location with corresponding marker. Traditional double markers could indicate the attenuation characteristics.
- Exquisite Design, Ideal for Fieldwork : Vibration proof, dust proof, humidity proof, 4.3’’ TFT Touch Screen, long operating hours and high capacity lithium battery make AE2300 ideal for fieldwork.
- Cost Effective : At same dynamic range, AE2300 has the most cost-effective price among all instrument.
- Long Operating Hour : Operating Hour > 8 hours
Auto Diagnosis and Auto Correction
−Optical adapter detection and protection
AE2300 triggers the alarm when light injection has been found at the optical adapter.
−Optical adapter connection detection
Warning is provided if optical adapter is stained in order to avoid influencing the test result.
−Self calibration and correction
Auto calibration function could self-calibrate the instrument after using a certain period of time
Visual Fault Locator(VFL )
High power visual fault locator could be used to locate fiber and find out the break out point within fiber.
Interface (RJ45, USB)
−RJ45 Remote control and data sharing
−USB Data transferring
−Optical Adapter Easy to replace and clean with lower cost
Specification
Parameters | |
Distance |
3m~160km |
|
Pulse Width |
AE2300 : 5ns~20μs AE2300H: 3ns~20μs |
Measurement Time |
User-defined |
Distance Uncertainty |
±(1m +0.0005%×Distance + Sampling Resolution) |
|
Loss Threshold |
AE2300L/AE2300: 0.05dB AE2300H/AE2300P-1/AE2300P-2/AE2300P-3: 0.03dB |
Loss Resolution |
0.001dB |
Distance Resolution |
0.05m |
Linearity |
0.04dB/dB |
Sampling Points |
128000 |
General |
|
Display |
4.3’’ 16:9 TFT Touch Screen |
Data Storage |
>4000 |
Optical Adapter |
FC/PC, SC/PC |
Interface |
USB, RJ45 |
Power Supply |
AC/DC Adapter, Input AC90-240V ±10%, Output 12V |
Operating Temperature |
-10 °C ~ 50 °C |
Storage Temperature |
-40 °C ~ 85 °C |
Relative Humidity |
<80% |
Weight |
<1kg |
Battery |
Lithium Battery; Charging <4 hours, Operating time >8 hours |
Accessory | |
SC/PC Adapter |
1 |
AC Adapter |
1 |
Quick Operating Guide |
1 |
Package Bag |
1 |
Disc |
Toolbox Software and User Manual |
