NEW Deviser SA8300A 9kHz~3GHz Portable Spectrum Analyzer

Name: NEW Deviser SA8300A 9kHz~3GHz Portable Spectrum Analyzer
Brand: Deviser
SKU: 130806395

NEW Deviser SA8300A 9kHz~3GHz Portable Spectrum Analyzer thumbnail-1

NEW Deviser SA8300A 9kHz~3GHz Portable Spectrum Analyzer photo-1

US$ 1 - 2 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Deviser

Model Number:

sa8300a

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Deviser

Model Number sa8300a

Specifications

3GHz Spectrum Analysis
Large Dynamic Range Spectrum
Interference Signals Analysis
Fast Sweep Speed
RF Signals Analysis

Deviser SA8300A Portable Spectrum Analyzer

Overview

SA8000 series spectrum analyzers are ideal testing instrument for engineer working, laboratory and production line. SA8300 covers 9kHz ~ 3000 MHz, and SA8600 covers 100 kHz ~ 6000 MHz, all of them have tracking generator option.

Large Dynamic Range Spectrum Analysis

SA8000 series covers wide frequency range and provide +15 dBm IP3 and lower noise.

Interference Signals Analysis

SA8000 series provides features such as signal strength indication,spectrogram and fluorogram to find out interference signals.

SA8000 series supports FM/AM demodulation and then distinguishes noise.

Fast Sweep Speed

SA8000 series provides 1 ms minimum sweep time to detect any complex interference signals.

RF Signals Analysis Function

SA8000 series provides one-button measurement for channel power,OBW and adjacent channel power.

Specifications

	SA8300A/B/C	SA8600A
Frequency
Frequency Range	9 kHz ~ 3000 MHz	100kHz ~ 6GHz
Frequency Reference
Aging	±1 x10-6/year
Stability	±1 x10-6
Temperature Stability	±2 x10-6(0 ~ +50)°C
Frequency Resolution	1 Hz
Marker Count Accuracy (S/N 25 dB, RBW/span 0.01)
Accuracy	±2 x10-6±1
Counter Resolution	1 Hz
Frequency Span
Range	0 H z, 1kHz ~ 3000 MHz	0 Hz, 1kHz ~ 6000MHz
Sweep and Trigger
Range	1ms ~ 1000s(span ≥ 1kHz) 10μ s ~ 250s(span= 0 Hz)	1ms ~ 1000s(span ≥ 1kHz) 10μ s ~ 250s(span= 0 Hz)
Accuracy	<±1%	<±0.2%
Trigger Type	Free run, Single, Video, Ext.
Resolution Bandwidth
Range	1 Hz ~ 3 MHz ,10% step
Selectivity (60 dB/3 dB Bandwidth Ratio)	< 5:1
Amplitude
Input Attenuator
Range	0 dB ~ 55 dB
Step	1dB manual, 5dB auto
Max. Safe Input	100VDC	50VDC
TOI	A≥12dBm, B/C≥15dBm	≥12dBm
Displayed Average Noise Level (Input Terminated, 0 dB Attenuator, RBW=1Hz, VBW=1Hz, Sample Detector)
Pre-amplifier OFF (Typical)	< -145 dBm 1 MHz ~ 1 GHz < -141 dBm 1 GHz ~ 3 GHz	≤-140dBm, 1 MHz ~ 1GHz ≤-136dBm, 1GHz ~ 3GHz ≤-126dBm, 3GHz ~ 6GHz
Pre-amplifier ON (Typical)	≤-160dBm, 1 MHz ~ 1GHz ≤-156dBm, 1GHz ~ 3GHz	≤-153dBm, 1 MHz ~ 1GHz ≤-151dBm, 1GHz ~ 3GHz ≤-141dBm, 3GHz ~ 6GHz
Display Range
Log Scale	0.1 ~ 0.9 dB/div, 0.1dB step, 1 ~ 40dB/div, 1dB step
Linear Scale	10div
Scale Units	dBm, dBmV, dBμV, mV
Reference Level	-130dBm ~ +30 dBm
Level Accuracy	≤±1.0dB@+25, ±5°C
Other Specifications
Operating Temperature	-10 ~ +55°C
Storage Temperature	-20 ~ +70°C
Dimension (W x H x D)	365mm260mm160mm
Weight (With Battery)	<4.5kg
Display Type	10.4 inch TFT color LCD
Display Resolution	800*600
Power Specifications	AC,100-240VAC, 50~60Hz, 20W
