UNI-T UTS1030 6.5''TFT-LCD 9kHz~ 2GHz Handheld Spectrum Analyzers
Features and Benefits:
6.5 inches Large High-Definition Screen forClear View;
Splendid and Vivid Structural Design;
Light-Weight, Compact, Easy to Carry With;
Offers 6600mAh Large-Capacity RechargeableBattery for Continuous Working up to 4 Hours;
Shares Similar Interface with that ofBench-Top Spectrum Analyzer
Offers better specifications than that ofprevailing portable spectrum analyzers prevailing in the market; Suitable forindoor and outdoor use.
Technicial Specifications:
Specification |
UTS1030 |
Spectrum Measurement | |
Range |
9kHz~3.6GHz |
Resolution |
1Hz |
Accuracy |
±(Frequency Marker Readout*Frequency Reference Accuracy +1%*Span +10%*RBW+0.5*[Span/(Sweep Points-1)]+1Hz) |
Internal Reference(10MHz) |
Aging Rate <1ppm/year |
Resolution Bandwidth (RBW) | |
Range |
10Hz~3MHz, Customized down to: 1Hz~10Hz |
Electability(60dB/3dB) |
RBW≤500kHz; <5:1 Typical (Digital implementation, next to Gaussian shape); |
Accuracy |
RBW≤500kHz; <5% Typical |
Video Bandwidth |
10Hz~3MHz |
Average Noise Level (1Hz RBW, 0dB RF Attenuator ) | |
Preamplifier Off |
100kHz~1MHz:<-100dBm-3×(f/100kHz)dB |
Preamplifier On |
100kHz~1MHz:<-120dBm-3×(f/100kHz)dB |
Phase Noise(fc=500MHz) | |
Offset 30kHz |
-90dBc/Hz |
Offset 100kHz |
-100dBc/Hz |
Offset 1MHz |
-110dBc/Hz |
Sweep Time | |
Span (100Hz≤SPAN≤3.6GHz) |
10ms to 3000s |
Zero Span |
1ms to 3000s |
Sweep Modes |
Continuous, Single |
Trigger | |
Trigger Source |
AUTO,Video,EXT |
Offset 100kHz |
5V TTL Level (Typical ) |
Frequency Counter | |
Resolution |
1Hz,10Hz,100Hz,1kHz |
Uncertainty |
Frequency Readout x Frequency Reference Progress +Counter Resolution |
Amplitude Accuracy (20℃~30℃) | |
Overall Amplitude Accuracy (90%) |
±1.5dB |
Amplitude | |
Max. Safe Input Level |
Average Continuous Power: +27dBm |
Max. Input DC Voltage |
50Vdc |
Input Attenuator Range |
0~39dB, in 3dB step |
1dB Compression |
+7dBm |
Internal Memory |
128MB |
Residual Response | |
Third-Order Intercept(TOI) |
>30MHz:+13dBm |
Second Harmonic Intercept(SHI) |
+30dBm |
Input Related Spurious |
<-60dBm |
Residual Response |
<-85dBm |
Tracking Generator (Optional) | |
Frequency Range |
100kHz to 1.5GHz |
Output Power |
-30dBm ~ 0dBm, in 1dB step |
Output Flatness |
±3dB |
Input/Output | |
RF Input |
N Type, Female (50Ω) |
USB |
USB Host,USB Device |
LAN |
10/100 Base-T, RJ-45 Connector |
AM/FM Demodulation |
Headset |
Reference Input/Output |
10MHz, BNC Female, Input: 0dBm ~ +10dBm;Output: 0dBm±2dB |
General Characteristics | |
Power |
Li-ion Battery: 7.4V 6600mAh; |
Display |
6.5 Inches TFT LCD, VGA (640×480) |
Product Color |
Red and Grey |
Product Net Weight |
3.0 Kg |
Product Size (W×H×D) |
182mm × 288mm ×142mm |
Standard Accessories |
DC Adapter,N/SMA Convertor,N/BNC Convertor, RF Cable, Antenna |
Standard Individual Packing |
Gift Box, English Manual, Warranty Card |
Standard Quantity Per Carton |
1 PC |
Standard Carton Measurement |
400mm × 280mm × 220mm |
Standard Carton Cross Weight |
3.9 Kg |
