Uni-t UPO2102CS Ultra Phosphor Oscilloscopes Digital Storge Oscilloscope 2 Channels 100MHz Bandwidth 1Gs/s Sample Rate
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UPO2102CS
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UTG9002C Signal Sources Signal Generators Function Generator 0.2Hz~2MHzNegotiableMOQ: 1 Piece -
Digital Storage Oscilloscope 50MHz 2Ch 7'' TFT LCD USB AC100-240V UTD2052CEXNegotiableMOQ: 1 Piece
-
UNI-T UTD4304C 4 Channels Digital Storage Oscilloscope 300MHz 2GS/s 24kpts Memory Depth USB Device USB Host Multimeter InterfaceNegotiableMOQ: 1 Piece
-
UNI-T UTD4102C 100MHz 2GSa/s 2 Channels Bench Digital Oscilloscope Logic Analyzer Multimeter 3 In1 USB AC 110-220VNegotiableMOQ: 1 Piece
-
UTG9002C 2MHz Desktop Digital Function Generator Signal GeneratorUS$ 100 - 160MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UPO2102CS
Uni-t UPO2102CS Ultra Phosphor Oscilloscopes Digital Storge Oscilloscope 2 Channels 100MHz Bandwidth 1Gs/s Sample Rate
Features and Benefits:
1,Sample Rate up to 1GS/s;
2,Channels 2/4;
3,Bandwidth 100MHz,160MHz,200MHz;
4,Memory Depth 32Mpts(Standard);
5,Waveform Capture Rate up to 30,000wfms/s;
6,With 256 level intensity grading display;
7,Up to 65,000 frames for Waveform Record ,Replay;
8,Support serial bus trigger and decoding;
9,8 inches, TFT LCD,WVGA(800*480);
10,Interface:USB Host, USB Device, LAN, VGA, AUX OUT, 10MHz input/output.
Technicial Specifications:
| Models | UPO2102CS |
| Bandwidth | 100 MHz |
| Channels | 2 |
| Sample Rate | 1GS/s |
| Max. Memory Depth | 32Mpts |
| Waveform Capture Rate | 30,000wfms/s |
| Time Base Scale | 2 ns/div - 50 s/div |
| Input Coupling | (1MΩ± 1%)||(13 pF± 3 pF) |
| Vertical Scale | 1mV/div -20 V/div(1 MΩ) |
| DC Gain Accuracy | ±3% |
| Waveform Record | 65,000 Frames |
| Trigger | Edge, Alternate, Runt, Super picture, Nth Edge, Delay, Duration, SetupHold, Pulse Width, Slope, Video, Pattern, RS232/UART,I2C,SPI, USB |
| Bus Decode | Standard: Parallel; Optional: RS232/UART,I2C,SPI, USB |
| Waveform Operation | A+B, A-B, A×B, A/B, FFT, Editable Advanced |
| Auto Measurement | Peak-Peak Value, Amplitude, Maximum, Minimum, Top Value, Bottom Value, Mean, Average, Root Mean Square Value, Overshoot, Preshoot, Frequency, Cycle, Rise Time, Fall Time, Positive Pulse, Negative Pulse, Positive Duty Ratio, Negative Duty Ratio, Delay 1->2, and Delay 2->1. |
| Number of Measurements | Display 5 measurements at the same time |
| Measurement Statistic | Average, Max, Min, Standard Deviation, Number of Measurements |
| Frequency Counter | Hardware 6 bits counter (Channels are selectable) |
| Standard Interface | USB-Host, USB-Device, LAN,10MHz Input/Output, AUX Output (TrigOut, Pass/Fail) |
| General Characteristic | |
| Power | 100V~240VACrms, 45Hz~440Hz |
| Display | 8 inches, TFT LCD, WVGA(800×480) |
| Product Color | White and Gray |
| Product Net Weight | 3.5 Kg ± 0.2 Kg |
| Product Size (W×H×D) | 336mm × 163.8mm × 105mm |
| Standard Accessories | Probe×2/4(1×,10× switchable),Power Cord ,USB Cable, PC Software CD |
| Standard Individual Packing | Gift Box, English Manual |
| Standard Quantity Per Carton | 2 PCs |
| Standard Carton Measurement (L×W×H) | 550mm × 220mm × 325mm |
| Standard Carton Cross Weight | 9.5 Kg |
Accessories
Probe×2/4(1×,10× switchable),
Power Cord ,
USB Cable,
PC Software CDD
