Digital Storage Oscilloscope 50MHz 2Ch 7'' TFT LCD USB AC100-240V UTD2052CEX
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD2052CEX
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UTD4304C 4 Channels Digital Storage Oscilloscope 300MHz 2GS/s 24kpts Memory Depth USB Device USB Host Multimeter InterfaceNegotiableMOQ: 1 Piece -
UNI-T UTD4102C 100MHz 2GSa/s 2 Channels Bench Digital Oscilloscope Logic Analyzer Multimeter 3 In1 USB AC 110-220VNegotiableMOQ: 1 Piece
-
UTG9002C 2MHz Desktop Digital Function Generator Signal GeneratorUS$ 100 - 160MOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2202CM 200MHz 1GS/s 16 Mpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 530MOQ: 1 Piece
-
DZD-6 Water and Mineral Detector, Multi-Function DC Resistivity & IP Instruments Underground Water DetectorUS$ 4,900 - 4,900MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD2052CEX
Digital Storage Oscilloscope 50MHz 2Ch 7'' TFT LCD USB AC100-240V UTD2052CEX
Introduction
1.Dual analog channels width range 1mV/div~20V/div;
2.7 inches widescreen LCD displays;
3.The new interface style;
4.Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
5.USB drive system software upgrade;
6.Storage of waveforms setups and interfaces waveforms and setups reproduction;
7.Automatic measurement of 32 waveform parameters;
8.Unique waveform recording and replay function;
9.Multilingual menu displays.
Specification
| Specification | UTD2052CEX | ||
| Channels | 2 | ||
| Bandwidth | 50MHz | ||
| Sample Rate | 1Gs/s | ||
| Rise Time | 7ns | ||
| Memory Depth | 25kpts | ||
| Waveform Acquisition Rate | 2000wfms/s | ||
| Vertical Sensitivity(V/div) | 1mV/div~20V/div | ||
| Timebase Range(s/div) | 2ns/div~50s/div | ||
| Storage | Setup,Wave,Bitmap | ||
| Trigger Modes | Edge, Pluse, Video,Slope,Alternate | ||
| Interface | USB OTG | ||
| General Characteristic | |||
| Power | 100-240VAC, 45-440Hz | ||
| Display | 7 Inches 64K Color TFT LCD, 800×480 | ||
| Product Color | White and Gray | ||
| Product Net Weight | 2.2 Kg | ||
| Product Size (W×H×D) | 306mm ×147mm × 122mm | ||
| Standard Accessories | Probe×2 (1×,10× switchable), Power Cord , USB Cable, PC Software CD | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 2 PCs | ||
| Standard Carton Measurement (L×W×H) | 450mm× 420mm × 280mm | ||
| Standard Carton Cross Weight | 8.5 Kg | ||
| Optional Accessories* | |||
| LA Module | |||
Accessory
1. Probe×2 (1×,10× switchable),
2. Power Cord,
3. USB Cable,
4. PC Software CD,
(Julie Zhou)
