Original TES PROVA 210 Solar Module Analyzer Prova-210
US$ 950 - 1,200
/ Piece
1 Piece(Min. Order)
- SHENZHEN
- T/T Money Gram Credit Card PayPal
You May Like
-
UTE1010A Uni-t Digital Power Meter True Rms Power Factor Analyzer 0.3W ~ 3000W
-
UNI-T UT70B LCD Digital Multimeter Frequency Conductance Logic Test Transistor Temperature Analog Display
-
Uni T Ut512 Insulation Resistance Tester Meter Ohm 2500v Usb Interface Ohm
-
2500V Digital Insulation Resistance Meter Tester Megohmmeter Highly Voltmeter Continuity Tester W/LCD Backlight UNI-T UT502A
-
UNI-T UT70C LCD Digital Multi-purpose Meter Multimeters Volt Amp Ohm Capacitance Tester UT-70C
-
Multifunctions Insulation Resistance Testers UNI-T UT529A Digital Earth Tester 125V/250V/500V Voltage Frequency Tester
Product Details
| Place of Origin | Taiwan, China | Brand Name | TES | |
| Model Number | PROVA 210 |
Product Description
Product Description
Original TES PROVA 210 Solar Module Analyzer Prova-210
Specification:
Electrical Specifications (23C±5C)
Voltage Measurement:
| Range (60V / 6A) | Resolution | Accuracy |
0–6V | 0.001V | ±1% ± (1% of Vopen ± 9mV) |
| 6 - 10V | 0.001V | ±1% ± (1% of Vopen ± 0.09V) |
10–60V | 0.01V | ±1% ± (1% of Vopen ± 0.09V) |
Current Measurement:
| Range (60V / 6A) | Resolution | Accuracy |
0–0.6A | 0.1mA | ±1% ± (1% of Ishort ± 0.9mA) |
| 0.6 - 1A | 0.1mA | ±1% ± (1% of Ishort ± 9mA) |
1–6A | 1mA | ±1% ± (1% of Ishort ± 9mA) |
Current Simulation:
| Range (60V / 6A) | Resolution | Accuracy |
0–1A | 0.1mA | ±1% ± 0.9mA |
1–6A | 1mA | ±1% ± 9mA |
General Specifications:
Battery Type: | Rechargeable, 2500mAh (1.2V) x 8 |
AC Adaptor: | AC 110V or 220V input, 12V/ 1 ~ 3A output |
Dimension: | 257 (L) x 155 (W) x 57 (H) mm 10.1 (L) x 6.1 (W) x 2.2 (H) in |
Weight: | 1160 g / 40.0 oz |
Accessories: | Users manual x 1, AC adaptor x 1 RS232C (to USB Bridge) Cable x 1 Rechargeable batteries x 8 Software CD x 1 Kelvin Clips (6A max) x 1 set |
