Handheld Insulation Resistance Tester UT505A Electrical Remote Test AC/DC 600V 20Gohm Megger Tramegger
US$ 100 - 140
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT505A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT204A Digital Clamp Multimeters Auto Range Temperature AC DC Current Clamp Meter Uni t UT 204A Ammeter VoltmeterUS$ 20 - 40MOQ: 5 Pieces -
Digital Earth Ground Testers UNI-T UT521 Electrical Earth Voltage DeviceUS$ 75 - 95MOQ: 1 Piece
-
Digital Earth Ground Testers UNI-T UT522 Electrical Earth Voltage DeviceUS$ 80 - 110MOQ: 1 Piece
-
200A Super Mini Pocket Clamp Meters UNI-T UT210A Multimeter AC DC Voltage SlimpElectronic Tester Diode Auto RangeUS$ 10 - 15MOQ: 5 Pieces
-
Professional Modern Digital Clamp Meters UNI-T UT200B Multimeter Resistance TesterUS$ 7 - 15MOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT505A
Display Type
Digital Only
Measuring Range
20Gohm
Testing Voltage
50V/100V/250V/500V/1000V
Accuracy Class
class 2
Operating Temperature
-40-1000
Dimensions
103mm * 225mm * 59 mm
Insulation Resistance Tester 1UNI-T UT513 000ohm Digital Megger Tramegger 500V/1000V/2500V/5000V USB Interface
Introduction
UT505A is a kind of handled insulation resistance tester, which has the parameters such as insulation resistance, AC/DC voltage and etc. This machine has high accuracy and stable
Performance with wide range of function. It apply to maintain, test and check the transformers, electrical machines, cables, switch, electric appliances and the other electrical equipments as well as insulation resistance with insulation materials. UT505A is your ideal choice.
Features
1. Show the actual value of insulation voltage 50V/100V/250V/500V/1000V
2. Insulation resistance can be test to 20GΩ
3. Measured absorptance / polarization index ,low –resistance test (20kΩ)
4. Step voltage regulation , the function of remote detection test lead and comparison
5. 600V AC/DC voltage ,99 data loging
6. Safety level: CAT III 1000V CAT IV 600V
7. Brand-new designed, portable and easy to control.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT505A | UT505B | ||
| Insulation Resistance(Ω) | Test Voltage | 50V/100V/250V/500V/1000V | 0%~10% | 0%~10% |
| 50V | 0.01MΩ~50.0MΩ | ±(3%+5) | ±(3%+3) | |
| 50.0MΩ~1.0GΩ | ±(3%+3) | |||
| 1.0GΩ~10GΩ | ±(10%+3) | |||
| 100V | 0.01MΩ~100.0MΩ | ±(3%+5) | ±(3%+3) | |
| 100.0MΩ~1.0GΩ | ±(3%+3) | |||
| 1.0GΩ~20GΩ | ±(10%+3) | |||
| 250V | 0.01MΩ~200.0MΩ | ±(1.5%+5) | ±(1.5%+5) | |
| 200.0MΩ~1.0GΩ | ±(1.5%+5) | |||
| 1.0GΩ~50GΩ | ±(10%+3) | |||
| 500V | 0.01MΩ~500MΩ | ±(1.5%+5) | ±(1.5%+5) | |
| 500MΩ~1.0GΩ | ±(1.5%+5) | |||
| 1.0GΩ~100GΩ | ±(10%+3) | |||
| 1000V | 0.1MΩ~2000MΩ | ±(1.5%+5) | ±(1.5%+5) | |
| 2.0GΩ~9.9GΩ | ±(10%+3) | ±(5%+3) | ||
| 10.0GΩ~20GΩ | ±(20%+10) | ±(7%+3) | ||
| 20GΩ~200GΩ | ±(20%+3) | |||
| Load Current | 50V(R=50KΩ) 1mA | 0%~10% | 0%~10% | |
| 100V(R=100KΩ) 1mA | 0%~10% | 0%~10% | ||
| 250V(R=250KΩ) 1mA | 0%~10% | 0%~10% | ||
| 500V(R=500KΩ) 1mA | 0%~10% | 0%~10% | ||
| 1000V(R=1MΩ) 1mA | 0%~10% | 0%~10% | ||
| Short Circuit Current | <2mA | <2mA | ||
| Leakage Current(A) | 10 ~ 2000 μA | ±(10%+3) | ||
| Low Resistance (Ω) | 0.01Ω~20.00KΩ(about 5.0V/>200mA) | ±(1.5%+3) | ||
| 0.01Ω~100Ω(about5.0V/>200mA/20mA Optional) | ±(1.5%+3) | |||
| General Resistance (Ω) | 0.01kΩ~1000KΩ | ±3%+2 | ||
| DC Voltage (V) | 0.0V~600.0V | ±(2%+3) | ±(2%+2) | |
| AC Voltage (V) | 0.0V~600.0V | ±(2%+3) | ±(2%+3) | |
| Frequency(Hz) | 45Hz ~450 Hz | ±0.1%+3 | ||
| Capacitance(F) | 100 pF ~10 μF | ±5%+5 | ||
| Features | ||||
| Display Count | 6000 | 6000 | ||
| Auto Range | √ | √ | ||
| True RMS | √ | √ | ||
| Step Voltage | 10% Steps at 50% ~ 120% of range | √ | √ | |
| DAR | 60s/15s and 60s/30s | √ | √ | |
| PI | √ | √ | ||
| Timer | √ | √ | ||
| High Voltage Indication | √ | √ | ||
| Auto Discharge | √ | √ | ||
| Fuse Seltf Test | √ | |||
| Analogue Bar Graph | √ | √ | ||
| Auto Power Off | √ | √ | ||
| Continuity Buzzer | √ | √ | ||
| Data Hold | √ | √ | ||
| Data Storage | 99 | 99 | ||
| Comparison | √ | √ | ||
| LCD Backlight | √ | √ | ||
| Low Battery Indication | √ | √ | ||
| General Characteristic | ||||
| Power | 1.5V Batteries(LR6) × 6 | |||
| LCD Size | 78mm × 59mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 630g | |||
| Product Size | 103mm × 225mm × 59 mm | |||
| Standard Accessories | Test Lead, Probe, Alligator Clip, Batteries | |||
| Standard Individual Packing | Carrying Bag, Gift Box, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 515mm × 380mm × 385mm (0.075 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 20 Kg | |||
| Optional Accessories | Remote Test Lead | |||
Accessory
1. Test Lead,
2. Probe,
3. Alligator Clip,
4. Batteries (not included because of the custom regulations)
