Digital Earth Ground Testers UNI-T UT521 Electrical Earth Voltage Device
US$ 75 - 95
/ Piece
1 Piece(Min. Order)
- FOB Shenzhen
- T/T Credit Card PayPal
You May Like
-
Digital Earth Ground Testers UNI-T UT522 Electrical Earth Voltage Device
-
200A Super Mini Pocket Clamp Meters UNI-T UT210A Multimeter AC DC Voltage SlimpElectronic Tester Diode Auto Range
-
Professional Modern Digital Clamp Meters UNI-T UT200B Multimeter Resistance Tester
-
UNI-T UT136D Handheld Auto-ranging Digital Multimeters Data Hold LCR Meter AC DC Frequency Resistance Automatic Range Multimeter
-
UNI-T UT136C Handheld Auto-ranging Digital Multimeters Data Hold LCR Meter AC DC Frequency Resistance Automatic Range Multimeter
-
Handheld Auto-ranging Digital Multimeters UNI-T UT136B Data Hold LCR Meter AC DC Frequency Resistance Automatic Range Multimeter
Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT521 | Display Type | Digital Only | |
| Measuring Range | 0-2000ohm | Testing Voltage | 0-200V | |
| Accuracy Class | ±(2%+3) | Operating Temperature | 5℃-40℃ | |
| Dimensions | 160mm*70.5mm*100mm |
Product Description
Digital Earth Ground Testers UNI-T UT521 Electrical Earth Voltage Device
Introduction
Grounding Resistance Tester UT520 is designed with intelligent micro-controller chip
to maintain high accuracy and reliability.
It can measure earth resistance of earth
ground devices for electric power installations, electrical appliances,
lightening protection systems, etc, and also measure earth voltage(It is highly
recommended not to use the Tester under severe outdoor environments such as raining or thunder).
Specification
| Specifications | Range | Best Accuracy | |
| Model | UT521 | UT522 | |
| Earth Resistance (Ω) | 0-20Ω | ±(2%+10) | |
| 0-200Ω | ±(2%+3) | ||
| 0-2000Ω | ±(2%+3) | ||
| 0-40Ω | ±(2%+20) | ||
| 0-400Ω | ±(2%+3) | ||
| 0-4000Ω | ±(2%+3) | ||
| AC Earth Voltage (V) | 0-200V | ±(1%+4) | |
| 0-400V | ±(1%+6) | ||
| Frequency50Hz/60Hz | √ | √ | |
| Features | |||
| Display Count | 2000 | 4000 | |
| Manual Range | √ | √ | |
| Auto Power Off | Around 10 Minutes | √ | √ |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| Data Logging | 20 | 20 | |
| LCD Backlight | √ | √ | |
| Full Icon Display | √ | √ | |
| Double Insulation Protection | √ | √ | |
| Contact Badness Display | Port C or Port E don`t contact Display"----Ω" | √ | √ |
| Over-Range Display | Display “OL" | √ | √ |
| Simple 2-Wires Testing | √ | √ | |
| Precision 3-Wires Testing | √ | √ | |
| General Characteristic | |||
| Power | 1.5V Alkaline BatteriesLR6X 6 | ||
| LCD Size | 70.6mm X 34mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 560g | ||
| Product Size | 160mm X 100mm X 70.5mm | ||
| Standard Accessories | Batteries, Carrying Bag, Test Lead, Simple Test Lead, Test Probe | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 8 PCs | ||
| Standard Carton Measurement | 615mm X 530mm X 190mm(0.062 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 15 Kg | ||
Accessory
1. Batteries, (not included)
2. Carrying Bag,
3. Test Lead,
4.Simple Test Lead,
5. Test Probe
(Julie Zhou)
