ACA826T Ultra High Accuracy Tilt Angle Sensor With Full Temperature Compensation MADE IN CHINA
- 30000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
- ACA626T Super High Precision Digital Inclinometer Tilt Sensor With Max Range +/-60deg High Resolution
- ACA Super High Precision CANOPEN Type Inclinometer Tilt Sensor With Full Temperature Compensation
- ACA2000 Super High Accuracy Dual axis Digital Servo Inclinometer Price With +/-30deg range & Temperature Sensor Output ,IP67
- SCA128T Marine Digital Clinometer Dual axis Tilt Sensor With 4-20mA Stable Output
- HCA526T High Precision Digital Clinometer With Stable Data & Temperature Output
- ACA626T MEMS horizontal In-Place Inclinometer With Dual axis Digital Output MADE IN CHINA
Product Details
Place of Origin: | Guangdong, China | Brand Name: | RION | Model Number: | ACA826T |
Usage: | Level Sensor | Theory: | Other, MEMS | Output: | Digital Sensor |
Packaging Details
1pcs/inner box with thick sponge, 100pcs/ctn
Product Description
ACA826T Ultra High Accuracy Tilt Angle Sensor With Full Temperature Compensation MADE IN CHINA
General Description
ACA826Tis a full temperature compensation & high accuracy dual-axis inclinometer which professionally developed by Rion Company to the field of high precision level measurement and leveling field , the maximum measuring range is± 3 °, high resolution 0.0005 °, can completely replace the traditional high-precision level meter. Digital signal transmission, matched with professional computer software, data measure and record correctly,output interface RS485, RS232, TTL, PWM or CAN 2.0B optional.Non-contact installation features make ACA826T with superior system integration, convenient installation only need fix the sensor on the measured surface by screws , then can automatically calculate the object horizontal inclined angle, easy to use .With strong ability resistance to external electromagnetic interference and to withstand shock and vibration,in the domestic counterparts products with absolute competitive advantage.
Features
- Dual-Axis Inclinometer
- Measuring Range :±1~±3° optional
- Size:L92×W48×H36mm
- Wide voltage input: 9~36V
- Wide temperature working: -40~+85°C
- IP67 protection class
- Resolution: 0.0005°
- Water-proof air-plug
- Highly anti-vibration performance >2000g
- Output mode RS232,RS485,RS422,TTL,CAN 2.0 are optional
Application:
- Engineering vehicles automatic leveling
- Bridge & dam detection
- Laser equipment position
- Medical facilities angle control
- Underground drill posture navigation
- Railway gauging rule , gauge equipment leveling
- Precise machine tool level control
- Geological equipment inclined monitoring
- Directional satellite communications antenna pitching angle measurement
Screen shot for ACA series Software :
Our Company & Workshop View :
Certificates & Test Reports :
We can offer :
- Reliable high quality products and services
- Perfect whole system application solution
- Strong technical support before or after sales service
- Extend strong sales teams & distributors global
- OEM products as buyer's requests
Our main products :
- Single/Dual-axis High accuracy Inclinometer (digital , current , voltage, CAN output type etc. )
- 2D / 3D Electronic Compass Sensor (RS232, RS485,TTL output, etc.)
- 1-Axis , 2-Axis, 3-Axis Accelerometer (digital , current , voltage output, etc.)
- 1-Axis , 2-Axis, 3-Axis Gyroscope((digital , current , voltage output, etc.)
- Single /Dual / Three-Axis Angular Gyro Sensor (RS232, RS485,TTL output, etc.)
- High performance MEMS Mini AHRS ( Attitude Heading Reference System )
- Other Agent Products PNI...etc
Order Process :
Before order pls contact us for confirm detailed informaiton such as model ,price ,lead time ...etc .
Payment ways :
T/T, WU or Paypal;
Delivery methods & Time :
DHL takes 3-5days , Fedex takes 2-7 days , UPS takes 3-7day , EMS takes 10-25days ;
Quality Policy :
We gurantee 1 year in free charge .
Storage :
Note usually we don't make any items in stock , samples customize time need around 3-7days .
Other more information please visit our website :
Now please contact us through below methods for your any requirement or comments !
Contact person : Ms kity(sales)
SHEN ZHEN RION TECHNOLOGY CO.,LTD
Factory Address:
3F/Block 5, HuaFeng Tech- Park, Xin'an Road 6 #, BaoAn Dis. Shenzhen, China
Tel : +86-755-29657137 ext 807 Cell phone: 15625295088
Fax : +86-755-29123494 MAIL: kiting AT
Skype: sz_rion_tech MSN: tradeofchina AT
RIONWEB: ALIWEB: http://rion.en.china.cn
Company Profile
RION Technology Co., Ltd. is located in a fantastic city - Shenzhen. Our company is a high technology company that integrates research, development, production and sale, and is mainly engaged in the sale of inclinometer sensors, digital compasses, digital dipmeters and acceleration sensors. These products are widely used in many industrial control fields, such as automobiles, ships, airplanes, railways, medical facilities, dam safety monitoring, oil drilling, coal mining and ocean surveying. Our company has established good business relationships with many international famous companies.
We adhere to the service guideline of "Client-centered". "Client uppermost, credit first, service best" is our business philosophy. Our company provides accurate, efficient, civilized and complete services for clients.
Let us provide you with the best products. To save purchasing cost and time, contact us now.
.
