Help CenterACA626T MEMS Horizontal In-Place Inclinometer With Dual Axis Digital Output MADE IN CHINA
Related Products
-
ACA826T Ultra Precision Electronic Level Slope Sensor With Strong Electromagnetic Interference Resistance PerformanceNegotiableMOQ: 1 Piece -
Waterproof High Precision Electronic Digital Level Inclinometer With Built-in Temperature SensorNegotiableMOQ: 1 Piece
-
SCA126T Standard Dual Axis Pitch Roll Output Type Sensor With High Resolution 0.01deg RS232/RS485/TTL CAN/MODBUS OptionalNegotiableMOQ: 1 Piece
-
ACA616T Ultra Precision Single Axis Slope Meter With Digital Output (RS232/RS485/TTL Optional) High Resolution 0.001degNegotiableMOQ: 1 Piece
-
HCA516T High Accuracy Digital Output Type Slope Meter With Wide Temperature Working , IP67 WaterproofNegotiableMOQ: 1 Piece
Specifications
1.Measuring Range :+/-1 ~ +/-30deg optional2.High Resolution: 0.001deg
3.Wide voltage input: 9~36V
4.IP67 protection class
ACA626T MEMS horizontal In-Place Inclinometer With Dual axis Digital Output MADE IN CHINA
General Description
ACA626T is a full temperature compensation & high precision dual-axis inclinometer which developed by Rion company based on high precision tilt angle platform ,the excellent temperature stability, can maintainhigher measurement accuracy in a wide temperature range of -40-85 degrees environment, is more suitable for long-term monitoring and leveling of the field equipment. In addition the system built-in high-precision 24it A / D differential converter, meanwhile by 5 filtering algorithm, which can measure the output of the sensor tilt and pitch angle relative to the horizontal. The output interface RS485, RS232, TTL, PWM or CAN 2.0B optional.Non-contact installation features make ACA626T with superior system integration, Simply fix the sensor on the measured surface by screws , then can automatically calculate the object posture inclination, easy to use , no need to find the relative change two surfaces for mounting . With strong ability resistance to external electromagnetic interference and to withstand shock and vibration,in the domestic counterparts products with absolute competitive advantage, specialized in application in the industrial and military fields where the high-end user requirements.
Features
- Dual-Axis Inclinometer
- Measuring Range :±1~±30° optional
- Wide voltage input: 9~36V
- Wide temperature working: -40~+85°C
- IP67 protection class
- Highly anti-vibration performance >2000g
- High Resolution: 0.001°
- Water-proof air-plug
- Size : 92×48×36mm
- Output mode RS232,RS485,RS422,TTL,CAN 2.0 are optional
Application:
- Engineering vehicles automatic leveling
- Bridge & dam detection
- Laser equipment position
- Medical facilities angle control
- Underground drill posture navigation
- Railway gauging rule , gauge equipment leveling
- Precise machine tool level control
- Geological equipment inclined monitoring
- Directional satellite communications antenna pitching angle measurement
Our Company & Workshop View :
Certificates & Test Reports :
We can offer :
- Reliable high quality products and services
- Perfect whole system application solution
- Strong technical support before or after sales service
- Extend strong sales teams & distributors global
- OEM products as buyer's requests
Our main products :
- Single/Dual-axis High accuracy Inclinometer (digital , current , voltage, CAN output type etc. )
- 2D / 3D Electronic Compass Sensor (RS232, RS485,TTL output, etc.)
- 1-Axis , 2-Axis, 3-Axis Accelerometer (digital , current , voltage output, etc.)
- 1-Axis , 2-Axis, 3-Axis Gyroscope((digital , current , voltage output, etc.)
- Single /Dual / Three-Axis Angular Gyro Sensor (RS232, RS485,TTL output, etc.)
- High performance MEMS Mini AHRS ( Attitude Heading Reference System )
- Other Agent Products PNI...etc
Order Process :
Before order pls contact us for confirm detailed informaiton such as model ,price ,lead time ...etc .
Payment ways :
T/T, WU or Paypal;
Delivery methods & Time :
DHL takes 3-5days , Fedex takes 2-7 days , UPS takes 3-7day , EMS takes 10-25days ;
Quality Policy :
We gurantee 1 year in free charge .
Storage :
Note usually we don't make any items in stock , samples customize time need around 3-7days .
