Specifications
Mechanical engineeringa utomatic leveling inclinometer1.Single axis vlotage-type
2.Long term stability<0.002degrees
3.IP68
HCA510T MEMS Based Voltage Type Single-axis Level Sensor, Full Metal Jacket, IP68 protection
General Description:
HCA510T is a Single-axis inclinometer(icrane,hoist,Special Machine,mechanical engineeringa utomatic leveling with voltage output. Its theory is measuring the change of Static acceleration of gravity. It used to compute the dip and pitch degree in respect to the horizontal plane. Product adopts the newest MEMS production technology, so it features high accuracy, small dimension and high anti-EM interference capability as well as under strong shock and impact. At present, it gained the consistent favourable comment of customer in the industry.
Features:
1:Single-axis inclinometer
2:DC 9-36V wide voltage power supply
3:Shockproof>20000g
4:0-5V Output interface
5:Full Metal Jacket,IP68 protection
6:Resolution0.0025°
7:Accuracy:0.003<5degrees,0.005<10degrees,0.01<15degrees
7:Wide Temperature-40-+100(Degrees Celsius)
8:small size(90*45*29mm)
Applications:
1:Push bench shield machine deviation
2Special vehicles automatic leveling
3:Platform Vehicle,lifter
4:Medical facilities angle control
5:Satellite positioning Search
6:Underground drill posture navigate
