Features
High speed RFID card reading/writing module
Mifare & Light standard compliant
High reliability, low power consumption design
Independent RFID board and main board
Auto-scan RFID card and anti-collision of multiple cards
Support Windows XP, Windows 7
Data storing spare for card reading. Writing and other functions
EMV & QPBOC certified
Provide various customized service
Quick Details
CRT-603-V10 is contactless RF module based on 13.56MHZ through RS232 interface.
Support ISO14443-3 MIFARE serial, including S50, S70, UL and PLUS S. Also support ISO14443-4 Type A and Type B.
Compliance with ISO7816 protocol.
Adapt for outside enviorment with feature of high security, reliability and robust life time. Be available for application in electrics, telecommunication, petroleum and financial industry.
Specification
|
Card type |
IC Card: ISO7816-1,2,3,4 Support T=0,T=1 PSAM Card RFID Card: ISO 14443 Type A & B Support Mifare I S50,S70,UL Card,Mifare Plus,Mifare desfire |
Communication Protocol |
PC/SC Protocol,CCID Driver |
Communication interface |
USB 2.0 |
Power supply |
DC 5V ± 5% |
Operating current |
Static: 200 mA Peak: 250 Ma |
Reading distance |
70mm( Depends on card) |
Operating frequency |
13.56 MHz |
Environmental conditions |
Operation:-10~60℃/0-95%RH( No condensing) |
Weight |
About 120 g |
Applications
- ATM
- Automatic fare collection(AFC) system
- ID identification system
- Card Management System
- Meter retail system
- Parking System
- Access control system
- Security terminal
- Payment kiosk
