Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader

Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader photo-1
Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader photo-2
Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader photo-3
Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader photo-4
Manual Insertion Samrt Card Reader for Self-service Terminal Hybrid Card Reader photo-5
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CRT, Creator
Model Number:
CRT-288C, CRT-288C
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hongkng
Delivery Detail:
Delivery time depends on order quantity.
Brand Name CRT, Creator
Model Number CRT-288C, CRT-288C
Place of Origin Guangdong, China

Manual insertion samrt card reader for Self-service Terminal hybrid card reader

Dip Card Reader CRT-288C



Model: CRT-288C







Quick Details



CRT-288C series are dip card reader equipments for RFID/IC /magnetic stripe card operation, with the function of the automatic card latch for locking.





Features



Dip card reader CRT-288C has below main features:



-    IC&RF card reading & writing, magnetic stripe card read only

-    Special baffle design for protecting reader from foreign object

-    Small dimensions, easy maintenance, cost efficient

-    Customization services

-    Two kinds of communication interface: USB&RS232

-    EMV certified





Applications



-    Self-service terminal

-    Recharging machine

-    Tanker

-    Media inquiry machine

-    Access control system

-    Vending machine

-    ATM





Specifications



Item

Description

Magnetic stripe

ISO 7810, 7811

Track 1,2,3 Hi-co/Lo-co read only

Contact smart card

ISO 7816-1,2,3,4

CPU card (T=0, T=1)

(Support)T=0,T=1 PSAM card

Contactless smart card (optional)

ISO 14443 type A & B, Mifare one, S50,S 70,ULMifare plus, and Desfire .

Interface

RS232/USB

Power

DC 12V±10%

Life time

Micro switch: 500,000 times Min  IC contact: 300,000 times Min



Environment conditions

Operation: 0℃~50℃,0~90% RH (Non condensing)

Storage: -25℃~80℃,0~95% RH (Non condensing)

Dimension

78mm (W) * 35.1mm (H) * 110.5mm (L)

Weight

Approx 200g





Competitive Advantages



-    RFID/IC card read/write, magnetic stripe card read only.

-    Electric card latch and release function. Card could be retrieved once latched if you pull by over 15 N of pulling force

-    RS232/USB interface (automatically detect interface)

-    Agile magnetic stripe reading type: Read when insert/withdraw and uploaded passively /actively

-    Long Life time (500,000 times)





Manual insertion samrt card reader for Self-service Terminal hybrid card readerManual insertion samrt card reader for Self-service Terminal hybrid card readerManual insertion samrt card reader for Self-service Terminal hybrid card readerManual insertion samrt card reader for Self-service Terminal hybrid card reader
