Shanghai Yixing ZG850 Cnc Machine Center
- Shanghai Shenzhen Ningbo Hubei
- T/T Credit Card PayPal
You May Like
-

                        Shanghai Cnc Vertical Lathe BX32 Torno Cnc Precio 4 Cnc Machine
-

                        VMC850 Centro de Mecanizado VMC NC Center Manufacturer CNC Machining Center,5-axis Machining Center,cnc Machining Center Vmc-850
-

                        Easy Operation ZG540 Precision l Vertical CNC Machining Center Lathe Parts
-

                        By-20 Metal Spinning Cnc Machine 4-aixs CNC Lathe Machine Price
-

                        Vertical Turning Andcnc Machining Center ZG850 , High Speed Precision Cnc Vertical Maching Center
-

                        Hot Sale!Yixing Mini High Performance Economic Vertical VMC Lathe CNC Machining Center Cnc Lathe
Product Details
| Condition | New | Type | Vertical | |
| Place of Origin | Shanghai, China | Brand Name | Yixing | |
| Model Number | ZG 850 | Voltage | 220V/380V | |
| Power(W) | 5.5/7.5KW | Dimension(L*W*H) | L2200*W2700mm | |
| Weight | 4000kg | Certification | ISO9001 | |
| Warranty | One Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High speed precision cnc vertical maching center Cnc Machine Center
1.Adopting the high-speed&high-precision spindle(12000/24000RPM),stable internal mechanical structure and excellent processing function, ZG850 Machine Center is suit for processing auto parts and communication aluminium alloy cavity.
2.Drilling and tapping is ultra high-speed/high performance/high-precision. Its tapping speed can reach 6000RPM and X/Y/Z axis’s movement speed can reach 50M/MIN.
3.Long traverse length,satisfies different processing needs on a large scale.
High speed precision cnc vertical maching center Cnc Machine Center Parameter
| Parts | items | unit | drilling and tapping center-ZG850 |
| Workbench | Size(L*W) | mm | 500*900 |
| Workbench load | kg | 350kg(even load) | |
| Spindle end to workbench face | mm | 150-650 | |
| Spindle | Spindle rotate speed | r/min | 12000/24000 |
| Spindle motor | kW | 5.5/7.5kW | |
| Hole conical degree | ISO | #30(BT30) | |
| Traverse | Travel X/Y/Z | mm | 800/500/500 |
| Rapid traverse speed X/Y/Z | m/min | 50/50/50 | |
| Cutting feed speed X/Y/Z | m/min | 20/20/20 | |
| Precision | Positioning accuracy | mm | 0.005/300 |
| Repeated positioning accuracy | mm | ±0.003 | |
| ATC | Magazine tool capacity | ea | 24+1(circle typl) |
| Max.tool Length | mm | 170 | |
| Max.tool dia | mm | 80 | |
| Max.tool weight | kg | 3 | |
| Tool to tool(T-T) | sec | 1 | |
| Power source | Power supply | kVA | 16 |
| Air source pressure | kgf/cm²(MPa) | 6(0.6) | |
| Motor | Dimension(L*W) | mm | L2200*W2700 |
| Dimension(H) | mm | 3000 | |
| Machine tool weight | kg | 4000 | |
| Cooling | Tank volume | L | 220 |
| Cooling pump flow | L/min | 60 | |
| Congtrol panel | Spec | MITSUBISHI/M70VB | |
| Screen | 8.4"Color TFT LCD | ||
| Storage of programme | KB | 500 |
High speed precision cnc vertical maching center Cnc Machine Center Pics

High speed precision cnc vertical maching center Cnc Machine Center:one in one standard wooden case.

Yixing Machinery Co.,LTD,It was established in 2005, The factory was located in Chinese famous province –Hubei Province,And it have bulid Research and development,procurement and sales center in Shanghai.
Company specialize in automotive, marine, medical, communications, electronics, mold and other industries,Our main products CNC lahte ,machine center ,bar feeder ,atuo lathe .Always provide a lot of efficient processing solutions , precision, stability is an industry leader, and made a number of national patents.
The company has always adhere to the "customer-centric" philosophy, adhere to the "customers interests is first" principle, as the most professional, most intimate workshop equipment.
