Most Popular CNC Machining Center CNC Lathe Taiwan Type Vertical Machining Center Vmc-850

Name: Most Popular CNC Machining Center CNC Lathe Taiwan Type Vertical Machining Center Vmc-850
Brand: yixing
Availability: InStock

FOB Price

US$ 48,000 - 53,000 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Vertical
Place of Origin	Shanghai, China	Brand Name	yixing
Model Number	VMC850	Voltage	220V/380V
Power(W)	7.5KW	Dimension(LWH)	245022302612
Weight	3000kg	Certification	ISO9001
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Most popular vmc 850 high speed Mitsubishi vertical machining center

1, Vertical machining center adopting the high-speed&high-precision spindle(12000/24000RPM),

2, Vertical machining center ZG850 Machine Center is suit for processing auto parts and communication aluminium alloy cavity.

3, Vertical machining center drilling and tapping is ultra high-speed/high performance/high-precision.

4, Vertical machining center tapping speed can reach 6000RPM and X/Y/Z axis’s movement speed can reach 50M/MIN.

5,Our Vertical machining center Long traverse length,satisfies different processing needs on a large scale.

Specifications about CNC machine center ZG850
Parts	items	unit	drilling and tapping center-ZG850
Workbench	Size(L*W)	mm	500*900
	Workbench load	kg	350kg(even load)
	Spindle end to workbench face	mm	150-650
Spindle	Spindle speed	r/min	12000/24000
	Spindle motor	kW	5.5/7.5kW
	Hole conical degree	ISO	#30(BT30)
Traverse	Travel X/Y/Z	mm	800/500/500
	Rapid traverse speed X/Y/Z	m/min	50/50/50
	Cutting feed speed X/Y/Z	m/min	20/20/20
Precision	Positioning accuracy	mm	0.005/300
Precision	Repeated positioning accuracy	mm	±0.003
ATC	tool capacity	ea	21
	Max.tool Length	mm	170
	Max.tool dia	mm	80
	Max tools weight	kg	3
	Tool to tool(T-T)	sec	1
Power source	Power supply	kVA	16
Power source	Air source pressure	kgf/cm²(MPa)	6(0.6)
Motor	Dimension(L*W)	mm	L2200*W2700
	Dimension(H)	mm	3000
	Net weight	kg	4000
Cooling	Tank volume	L	220
Cooling	Cooling pump flow	L/min	60
Congtrol panel	Spec		MITSUBISHI/M70VB
	Screen		8.4"Color TFT LCD
	Storage of programme	KB	500

Most popular vmc 850 high speed Mitsubishi vertical machining center pictures

1, Vertical machining center ZG850 using the original disc magazine, tool change time of just one second, reducing non-cutting time, improve the processing efficiency .

2. Vertical machining center by Renishaw laser interferometer, ballbar correction, so that precise positioning of the machine, repeat positioning accuracy for optimum stability.

3. Vertical machining center this model is particularly suitable for aluminum, copper alloy, resin and other materials as well as drilling and tapping cool cutting, face milling processes .

4. Vertical machining center operating system has high reliability, high-speed mobile all axes of 24m / min or more, the unique structure of the collet opening and closing, freely overlap processing, improve processing efficiency, reduce business costs .

Machine Model: ZG850 Vertical Machine Centers
Type of package: Plywood case

Packaging size: 240*290*310 CM(one set in one case)

N.W./G.W.: 4000 KGS

GUARANTEE &AFTER-SVRVICE:

1.Guarantee for one year

2.24-hour technical support by email or on line

3.User-friendly English manual for machine using and maintaining

4.Free technician training for large customers.

5. Provide Engineers oversea training for our customers

6.We could provide OEM .

Yixing Machinery Co.,LTD,It was established in 2005, The factory was located in Chinese famous province –Hubei Province,And it have bulid Research and development,procurement and sales center in Shanghai.

Company specialize in automotive, marine, medical, communications, electronics, mold and other industries,Always provide a lot of efficient processing solutions , precision, stability is an industry leader, and made a number of national patents.

The company has always adhere to the "customer-centric" philosophy, adhere to the "customers interests is first" principle, as the most professional, most intimate workshop equipment.
