Huawei AP6310SN-GN Access Point wide-coverage Fit AP combined 2G/3G networks, WLAN over CATV (WoC)
AP6310SN-GN Access Point
Huawei AP6310SN-GN AP is ideal for wide-coverage WLAN scenarios with high signal attenuation, such as hotels and office buildings. This 802.11n Fit AP delivers robust wireless access in distributed AP/feeder networks, combined 2G/3G networks, WLAN over CATV (WoC), and WLAN over Ethernet (WoE). In WoC and WoE scenarios, the AP6310SN-GN works with existing CATV or Ethernet cable resources to transmit WLAN signals — no wall drilling or extra cabling is required.
WLAN coverage and connectivity is easy with the AP6310SN-GN from Huawei.
Features
- Get an adaptable, low-maintenance WLAN for indoor distribution systems with proven Huawei reliability
- 150 Mbit/s indoor distributed coverage (single band: 2.4 GHz); complies with IEEE 802.11b/g/n; uses a metal shell and heat dissipation design to ensure high reliability
- IEEE 802.3af/at PoE and Plug-and-Play (PnP) simplifies installation
- Easy to maintain: Local AP management through the serial interface or Telnet; supports unified mobility management on the AC or NMS
- Strong environmental adaptability: Automatically selects transmission rates, channels, and transmit power to optimize transmission and avoid radio interference; adjusts bandwidth allocation as needed
- Enhanced network security includes multiple authentication and encryption modes and security protection; supports unified access controls and policies on the AC
Specifications
Specifications |
AP6310SN-GN |
Dimensions (H x W x D) |
150 mm x 130 mm x 35 mm |
Power Input |
12V DC ± 10% PoE: −48V DC (in compliance with IEEE 802.3af/at) |
Maximum Power Consumption |
8.3W |
Operating Temperature |
−10℃ to +50℃ |
Antenna Type/Antenna Gain |
Built-in antenna/2.4 GHz: 2 dBi, 5 GHz: 2.5 dBi |
Maximum Number of Concurrent Users |
≤ 128 |
Maximum Transmit Power |
27 dBm |
MIMO: Spatial Streams |
1 x 1:1 |
Radio Protocols |
802.11b/g/n |
Maximum Speed |
150 Mbit/s |
Specifications
Item |
Description |
|
Technical specifications |
Dimensions (H×W×D) |
35 mm×130 mm×150 mm |
Weight |
0.6 kg |
|
System memory |
128 MB DDR2 |
|
Power specifications |
Power input |
DC 12V±10% |
Maximum power consumption |
8.3 W |
|
Environment parameters |
Operating temperature |
-10°C to +50°C |
Storage temperature |
-40°C to +70°C |
|
Humidity |
5% to 95% (non-condensing) |
|
Waterproof grade |
IP31 |
|
Altitude |
–60 m to 4000 m |
|
Radio Specifications
Item |
Description |
Radio connector type |
N type (Female) |
Antenna type |
depends on the type of antennas in the indoor antennas system. |
Maximum number of concurrent users |
128 |
Maximum transmit power |
27 dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB. |
Maximum number of non-overlapping channels |
802.11b/g |
About the distribution:
As a golden distributor of HUAWEI, all of HUAWEI prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The HUAWEI products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
