Huawei AP6010 AP6010DN-AGN AP6010SN-GN AP6010SN-GN-CN 2 x 2 MIMO 2.4 GHz 5 GHz bands Indoor AP
AP6010 Series Access Points
Huawei AP6010 series APs boost the coverage and quality of WLAN connections for delay-sensitive services and high-bandwidth applications, such as VoWLAN and multimedia streaming. Offering both high capacity and pervasive coverage, AP6010 series APs work best in simple building structures with open/semi-open wireless environments that have a high density of users needing quality wireless services — scenarios that include enterprise offices, campuses, hospitals, large shopping malls, and exhibition centers.
Step up to a high-performance WLAN and optimize quality and coverage for wireless users.
Features
- Deliver real-time wireless network services with better quality and coverage
- High-speed, reliable 802.11n wireless access services with 2 x 2 MIMO technology — 20 dBm transmit power for each radio port ensures better coverage, efficiency, and reception for real-time services
- Energy-saving, elegant design: Green Certified, iF Award winner for Industrial Design
- AP6010SN-GN is 802.11b/g/n compatible and supports the 2.4 GHz frequency band for data rates up to 300 Mbit/s; AP6010DN-AGN is 802.11a/b/g/n compatible and supports 2.4 GHz and 5 GHz bands for data rates up to 600 Mbit/s with both radio frequenciess
- Rich QoS features include priority-based data processing and forwarding, user-based bandwidth limiting, adaptive bandwidth management, and dynamic management of radio interference
- Multiple authentication and encryption modes and security protections ensure security
Specifications
Specifications |
AP6010DN-AGN |
AP6010SN-GN |
Dimensions (H x W x D) |
180 mm x 180 mm x 50 mm |
180 mm x 180 mm x 50 mm |
Power Input |
12V DC ± 10% PoE: –48V DC (in compliance with IEEE 802.3af/at) |
12V DC ± 10% PoE: –48V DC (in compliance with IEEE 802.3af/at) |
Maximum Power Consumption |
10.2W |
6.5W |
Operating Temperature |
–10℃ to +50℃ |
–10℃ to +50℃ |
Antenna Type/Antenna Gain |
Built-in antenna/2.4 GHz: 4 dBi, 5 GHz: 5 dBi |
Built-in antenna/4 dBi |
Maximum Number of Concurrent Users |
≤ 128 |
≤ 128 |
Maximum Transmit Power |
23 dBm (combined power) |
23 dBm (combined power) |
MIMO: Spatial Streams |
2 x 2:2 |
2 x 2:2 |
Radio Protocols |
802.11a/b/g/n |
802.11b/g/n |
Highest Rate |
600 Mbit/s |
300 Mbit/s |
Specifications
Item |
Description |
|
Technical specifications |
Dimensions (H×W×D) |
50 mm×180 mm×180 mm |
Weight |
0.4 kg |
|
System memory |
128 MB DRAM |
|
Power specifications |
Power input |
DC 12V±10% |
Maximum power consumption |
AP6010DN-AGN: 10.2 W |
|
Environment parameters |
Operating temperature |
-10°C to +50°C |
Storage temperature |
-40°C to +70°C |
|
Humidity |
5% to 95% (non-condensing) |
|
Waterproof grade |
IP31 |
|
Altitude |
-60m to 4000 m |
|
Radio Specifications
Item |
Description |
|
Antenna type |
Built-in antenna |
|
Antenna gain |
AP6010DN-AGN |
|
Maximum number of concurrent users |
128 |
|
Maximum transmit power |
20dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB. NOTE:Actual transmit power depends on local laws and regulations. |
|
Maximum number of non-overlapping channels for AP6010DN-AGN |
2.4 GHz |
5 GHz |
NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status | ||
Maximum number of non-overlapping channels for AP6010SN-GN |
802.11b/g |
|
NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status | ||
About the distribution:
As a golden distributor of HUAWEI, all of HUAWEI prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The HUAWEI products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
