LC-120UV-2 Automatic Two Colour Cylinder UV Machine Serigraphie

LC-120UV-2 Automatic Two Colour Cylinder UV Machine Serigraphie photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Screen Printer
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Screen Printer
Place of Origin Guangdong, China
Brand Name LC
Model Number LC-120UV-2
Usage Bill Printer, Label Printer, Tube Printer
Automatic Grade Automatic
Voltage AC380V
Gross Power 50W
Dimensions(L*W*H) 1900*1000*1500mm
Weight 2050kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



Product Description

Description

LC-120UV-2 Automatic two colour cylinder UV machine serigraphie  This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of two-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc

Specifications

1 Model No:LCB-120UV-2
2.Printing colors:2 color

3.Product appearance:Round bottle /  oblate bottle
4.Operation:Full Auto
5.min printing diameter:round bottle: 20 mm
6.max printing diameter:round bottle :100 mm
7.min printing radius:oblate bottle :25 mm
8.max printing radius:oblate bottle :260 mm
9.oblate bottle width:20-100 mm
10.oblate bottle thickness:20-80 mm
11.Max Printing speed:4000-5000Pcs/Hr
12.Power:380V
13.Weight:2050(kg)

14.Dimensions:L:1900×W:1000×H:1500(mm)





Advantage

1.Full automatically printing suitable to print on various shades of cylindrical, elliptical and falt workpieces;

2.Coupled with auto workpiece feeding and loading system;

3.Flame treatment device adopted for re-treatment on PE or PP workpieces to get ultimate ink adhesion;
4
.The function of workpiece placing in advance is built-in aiming on cylindrical or elliptical printing;
5
.Electric sensor creates "no workpiece no printing" that leads to intelllgent monitor and smart control;
6
.High quality UV curing system adopted to ensure fast ink drying and color registration;
7
.High printing speed that up to 4000pcs/hr will bring you with high productivity;
8.
Conveniently and easily fixture adjustment and change that save your valuable time;
9.
Multi-sets of this machine can achieve 2-color, 3-color and even 4-color auto printing system



Picture of machine

 LC-120UV-2 Automatic two colour cylinder UV machine serigraphie



Picture of sample:

LC-120UV-2 Automatic two colour cylinder UV machine serigraphieLC-120UV-2 Automatic two colour cylinder UV machine serigraphie









Packaging & Shipping

 all machine is packed in wood case, shipped by sea or air.



LC-120UV-2 Automatic two colour cylinder UV machine serigraphieLC-120UV-2 Automatic two colour cylinder UV machine serigraphie







Our Services

  In order to protect the rights and interests of each user, each printing machine has to undergo a rigorous inspection and testing in factory before sold out as to deliver the most comprehensive after-sales service. Our company's goal: First-class quality, first-class technology, provide customers with first-class products and services
