Scope of application:
IT, daily necessities, food packaging and other industries within the plane objects, such as electronic products, shell, toys, etc.
Function description:
1, synchronous feeding (optional)
2, flame treatment system
3, mechanical automatic print system
4, automatic unloading systemVersion
5, pneumatic net lift function (with net washing), touch screen operation, low pressure, overloading and overheating alarm automatic monitoring and other functions
6, optional high temperature oven or UV ultraviolet furnace
7, the whole machine electrical components and the control system adopts the German and Japanese components, ensure the machine running stable.
Main parts:
1. MAIN MOTOR: SITI(Italy)
2. PLC: Omron(Japan)
3. SENSOR: Optex(Japan)
4...TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. (CONTACTOR): (Schneider)(France)
7(RELAY): (Idec)(Japan)
8. (INVERTER): Omron(Japan)
9. (UV CURING)(Primarc brand uv lamp ) Britain
10. (PNEUMATIC): Festo(Germany)
Technical parameters:
model:LC - HR108
The biggest printing area:L120 x120mm (can make to order a larger size)
The fastest printing speed:4000 / hour
Power requirements:220 v / 380 v
Volume (length x width x height):1900 x 1200 x 1600
Amount of weight:800 kg.
| Price Terms | FOB SHENZHEN PORT CHINA |
| Packing | wooden case |
| Lead Time | 25 days after deposit |
| Standards Certificate | CE |
| Volum | 4.8 |
| Application area | package of cosmetic, lipstick, bottles. |
| Gross Weight | 1100KG |
| Main Parts | 1. MAIN MOTOR: SITI(Italy) ,3. SENSOR: Optex(Japan) |
| Free Fittings |
SILK SCREEN PLATE ,SQUEEGEE
|
LC-HR108 Automatic Plane UV Silkscreen Machine
LC-HR108 Automatic Plane UV Screen Printer samples
all machine is packed in wood case, shipped by sea or air
