Home > Industrial Equipment & Components > Power & Generating Sets > Wind Generator > Weichai 500-1670kW Series Land Standard Diesel Generating Sets

Weichai 500-1670kW Series Land Standard Diesel Generating Sets

Name: Weichai 500-1670kW Series Land Standard Diesel Generating Sets
Brand: Weichai
SKU: 112656601
Availability: InStock

Weichai 500-1670kW Series Land Standard Diesel Generating Sets thumbnail-1

Weichai 500-1670kW Series Land Standard Diesel Generating Sets photo-1

US$ 5,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Weichai

Model Number:

500-1670kW Series

Contact Supplier Request Quote Chat Now

Xiamen Sitaiqi Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or other ports in China Mainland

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Weichai

Model Number 500-1670kW Series

Type Generator

Electricity Generator Type Other, Diesel Genset

Output Voltage (V) 400

Product Description

The 500-1670kW Series Land Standard Genset adopts internationally advanced CW200 series diesel engines manufactured by Weichai as its power source, and equipped with brand name generator. The engine and the generator are connected by flexible coupling and mounted on common fixing pedestal. This series Genset reaches A (Excellent) level in vibration test. Its technological parameters are in compliance with Generating Set ISO8528 and have passed CE conformity. Its NOx emission complies with supplementary article VI Clause No. 13 of No73/78 International Convention for the Prevention of Pollution and has obtained EIAPP certificate. It has advantages inclusive of high power, low fuel consumption, high reliability, long durability and easy maintenance, etc. MGO, MDO and HFO can be used.

Features:

High reliability and long durability with TBO reaching 25,000 hours. It is particularly suitable used as power station for daily use in remote areas, on small islands and oil fields.
Low costs when used as HFO power station for daily use.
High generator efficiency (0.93~0.95), small voltage waveform distortion, excellent dynamic performance. Insulation grade ≥F Class. Protection grade≥IP23.
Low fuel consumption, low vibration, stable operational performance.
Automated Genset can realize automatic start-up, au

Main Technical Data

500-1670kW Series Open Standard Generating Sets

Set model	Rated power(kW)	Rated voltage (V)	Fuel consumption at rated load (L/h)	Weichai CW200 Series Diesel Engine						Excitation mode
Set model	Rated power(kW)	Rated voltage (V)	Fuel consumption at rated load (L/h)	Engine model	Rated power(kW)	Rated speed (r/min)	No. of cylinders	Bore×Stroke(mm)	Cooling method	Excitation mode
WD687.5/6	500	400/230	118	CW6200ZD	600	1000	6	200×270	Open water cooling	Brushless
WD866/6	630	400/230	151	XCW6200ZD	698	1000	6	200×270	Open water cooling	Brushless
WD907.5/6	660	400/230	158	XCW6200ZD-1	720	1000	6	200×270	Open water cooling	Brushless
WD962.5/6	700	400/230	168	CW8200ZD	800	1000	8	200×270	Open water cooling	Brushless
WD1100/6	800	400/230	192	XCW8200ZD	928	1000	8	200×270	Open water cooling	Brushless
WD1237.5/6	900	400/230	216	XCW8200ZD-1	960	1000	8	200×270	Open water cooling	Brushless
WD1375/6	1000	400/230	240	CW12V200ZD	1200	1000	12V	200×270	Open water cooling	Brushless
WD1650/6	1200	400/230	288	XCW12V200ZD-1	1440	1000	12V	200×270	Open water cooling	Brushless
WD2062.5/6	1500	400/230	360	CW16V200ZD-6	1600	1000	16V	200×270	Open water cooling	Brushless
WD2296/6	1670	400/230	400	CW16V200ZD	1760	1000	16V	200×270	Open water cooling	Brushless
The frequency of generating sets listed in this table is 50Hz (60Hz generating sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.

500-860kW Series Close General Generating Sets

Set model	Rated power(kW)	Rated voltage(V)	Fuel consumption at rated load(L/h)	Weichai CW200 Series Diesel Engine						Excitation mode
Set model	Rated power(kW)	Rated voltage(V)	Fuel consumption at rated load(L/h)	Engine model	Rated power (kW)	Rated speed (r/min)	No. of cylinders	Bore×Stroke(mm)	Cooling method	Excitation mode
WD687.5/6	500	400/230	118	CW6200ZD	600	1000	6	200×270	Close water cooling	Brushless
WD825/6	600	400/230	142	XCW6200ZD-1	720	1000	6	200×270	Close water cooling	Brushless
WD962.5/6	700	400/230	168	CW8200ZD	800	1000	8	200×270	Close water cooling	Brushless
WD1100/6	800	400/230	192	XCW8200ZD	928	1000	8	200×270	Close water cooling	Brushless
WD1182.5/6	860	400/230	207	XCW8200ZD-1	960	1000	8	200×270	Close water cooling	Brushless
The frequency of generating sets listed in this table is 50Hz (60Hz generating sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.

Product Application

Weichai land gen-sets are widely uses as lighting power in factory, drilling, railway, agriculture and others; as mobile power in broadcast communication, flood control and drought relief, engineering construction; as emergency standby power in hospital, hotel , school and other public facilities. Weichai land gen-sets are widely used in national defense, shipping, telecommunication, petroleum, working on plateau, mineral mining, aquaculture, real estate, construction site, traffic and other fields.
