Weichai 10-50kW Series Land Standard Genset

Name: Weichai 10-50kW Series Land Standard Genset
Brand: Weichai
SKU: 112656655
Availability: InStock

Weichai 10-50kW Series Land Standard Genset thumbnail-1

Weichai 10-50kW Series Land Standard Genset photo-1

US$ 5,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Weichai

Model Number:

10-50kW Series Land Standard Genset

Contact Supplier Request Quote Chat Now

Xiamen Sitaiqi Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or other ports in China Mainland

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Weichai

Model Number 10-50kW Series Land Standard Genset

Type Generator

Electricity Generator Type Other, Diesel

Output Voltage (V) 400

Product Description

The 10-50kW Series Land Standard Genset adopts YZ series diesel engines manufactured by Weichai Yangzhou Diesel Engine Co., Ltd. as its power source, equipped with brand name generators and high-performance control system. It has advantages of good appearance, high reliability, stable performance, high accuracy in pressure adjustment and easy maintenance. According to control functions, it can be further divided into regular Genset and automated Genset. It is manufactured and tested according to ISO 8528 and GB/T2820 standards. Strictly in compliance with ISO9001 Quality Control System and European CE Safety Certification Standard, we have obtained TLC certificate.

Features:

It delivers excellent performances.
With excellent strength and rigidity, 10-50kW series Genset reaches high stability and reliability in operation.
Its generator is safe and reliable.
It uses brand name generators with an insulation Grade ≥ F Class.
It can easily start up and stop.
It can start up quickly and reach a full load in a short time.
It is highly economic.
Low overall costs, high fuel economy and high thermal efficiency. Its fuel consumption curve changes slightly under changing working conditions. It is also highly economic under low load.

Main Technical Data

10-50kW Series Standard Generating Sets

Set model	Rated power(kW)	Rated voltage(V)	Fuel consumption at rated load(L/h)	Weichai YZ Series Diesel Engine						Excitation mode
Set model	Rated power(kW)	Rated voltage(V)	Fuel consumption at rated load(L/h)	Engine model	Rated power(kW)	Rated speed(r/min)	No. of cylinders	Bore×Stroke(mm)	Cooling method	Excitation mode
WD13.5/1	10	400/230	2.5	WP2.1D18E2	18	1500	4	85×92	Close water cooling	Brushless
WD16.5/1	12	400/230	3.0	WP2.1D18E2	18	1500	4	85×92	Close water cooling	Brushless
WD22/1	16	400/230	4.0	WP2.5D22E2	22	1500	4	90×100	Close water cooling	Brushless
WD27.5/1	20	400/230	5.0	WP3.9D33E2	33	1500	4	102×118	Close water cooling	Brushless
WD30/1	22	400/230	5.5	WP3.9D33E2	33	1500	4	102×118	Close water cooling	Brushless
WD33/1	24	400/230	6.0	WP3.9D33E2	33	1500	4	102×118	Close water cooling	Brushless
WD34/1	25	400/230	6.3	WP3.9D33E2	33	1500	4	102×118	Close water cooling	Brushless
WD41/1	30	400/230	7.5	WP4.3D38E2	38	1500	4	105×125	Close water cooling	Brushless
WD44/1	32	400/230	8.0	WP4.3D38E2	38	1500	4	105×125	Close water cooling	Brushless
WD55/1	40	400/230	10.0	WP4.1D50E2	50	1500	4	105×118	Close water cooling	Brushless
WD66/1	48	400/230	12.0	WP4.3D61E2	61	1500	4	108×118	Close water cooling	Brushless
WD68.5/1	50	400/230	12.5	WP4.3D61E2	61	1500	4	108×118	Close water cooling	Brushless
The frequency of generating sets listed in this table is 50Hz (60Hz generating sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.

Product Application

Weichai land gen-sets are widely uses as lighting power in factory, drilling, railway, agriculture and others; as mobile power in broadcast communication, flood control and drought relief, engineering construction; as emergency standby power in hospital, hotel , school and other public facilities. Weichai land gen-sets are widely used in national defense, shipping, telecommunication, petroleum, working on plateau, mineral mining, aquaculture, real estate, construction site, traffic and other fields.
