LED CCD Fast Scan Spectroradiometer with Double Photo-Detectors
FEATURES:
1. Run under the Windows XP, Windows 98 operation system.
2. SMA905 fiber connector and CCD fast canning speed.
3. Connect with computer to save the data as PDF file or Excel file for analysis purpose.
4. A set of mainframe cooperate with power meter, AC power source, integrating sphere and etc. can completely fulfil the testing about photometry, colorimetry and electricity.
5. The system is not only suitable for labs, QC departments and R&D departments, but also for production line.
CHRACTERISTICS AND SPECIFICATIONS
The system can determine spectral power distribution, chromaticity coordinates, correlated color temperature (CCT), color rending index, SDCM, peak wavelength, spectral half width, dominant wavelength, color purity, luminous flux and etc.
1. Test speed:5ms-2s;
2. Range of wavelength: 380~780nm;
3. Accuracy of wavelength: ±0.3nm;
4. Accuracy of chromaticity coordinates: ±0.0015(x, y);
5. Range of dominant wavelength: 380~780nm;
6. Accuracy of dominant wavelength: ±0.5nm;
7. Correlative color temperature: 1000K—100000K, resolution:1K
8. Range of luminous intensity: 10mcd~3000cd (available with optical device)
9. Range of luminous intensity: 10mlm~20000lm(depending on the size of sphere);
10. Accuracy of electrical parameters: ±5%;
11. Accuracy of photometry: class1.
12. Range of forward current(IF):0.1mA~5.0A;
13. Range of forward voltage(VF):0.1~40.00V;
14. Range of reverse current(IR):0.1μA~200μA;
15. Range of reverse voltage(VR):0.1~30.00V;
16. A high degree of intelligent instruments with high stability and repeatability, it is completely satisfied with CIE measurement requirement;
