Specifications
1)Best value electrochemical reaction furnace2) CE, ISO9001 certificate
3) 100% Chinese manufactruer, factory direct price
1100 degree C Electrochemical reaction furnace SGGL-1100
SGGL -1100 crucible furnace with doped molybdenum resistance wire as heating elements, adopted polycrystalline alumina fiber as furnace chamber. Double shell design, ensure the lower temperature of the furnace shell; Heating kettle adopted high temperature resistance, corrosion-resistant alloy materials; With water-cooled flange, gas-tight sealed well; kettle lid with electrodes monitoring hole, according to the response of the electrode current to monitoring inner vessel; It is the ideal heater for the electrochemical reaction.
1.Resistance wire double helical winding, effectively elimination of the magnetic field generated by the heating elements within the reactor;
2. Reaction kettle adopted high temperature resistance, corrosion resistance and pressure resistance alloy material, effectively reduce the reaction of the acid corrosion; Water cooled sealing, good air tightness;
3. Built-in electrodes, real-time measurement of the reaction conditions, the built - in high-precision thermocouple, to ensure the reaction temperature is more accurate;
4. Automatic pressure relief and over temperature alarm, leakage protection, used safety and reliability.
Applicable to the electrochemical reaction and experimental.
Model |
SGGL-1100 (Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1) |
Heating kettle size |
Φ170*270*450mm (Customizable) |
Temperature control model |
The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 30 the heating and cooling program |
Heating elements |
0Cr27Al7Mo2 |
Control, monitoring components |
N mode thermocouple + S mode thermocouple |
Working temperature |
≤1000℃ |
Maximum temperature |
1050℃ |
Constant temperature accuracy |
±1℃ |
Ultimate vacuum |
≤0.1Pa |
Max pressure |
≤0.15MPa |
Heating power |
3KW |
Power supply |
AC220V 50HZ/60HZ |
Overall size |
460*460*650mm |
Send Inquiry to This Supplier
