Produce Battery Protective Atmosphere Sintering Furnace SZFL-1100

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SIOMM		Model Number	SZFL-1100
Place of Origin	Shanghai, China

1)Best value Produce battery protective atmosphere sintering furnace
2) CE, ISO9001 certificate
3) 100% Chinese manufactruer,

Produce battery protective atmosphere sintering furnace SZFL-1100

Detailed Images

Functions

1. Unique production and sealing of the furnace chamber, effectively ensure the air tightness

of the furnace, and according to the different requirements can equipped with vacuum pumps or

high vacuum system.

2. Adopted import alumina polycrystalline fiberboard as furnace chamber, with good insulation

and energy saving. Heating element (electric resistance wire) is easy installation and replacement.

3. Multi-point temperature control, multi-sides heating and multi-channel gas supply,

effectively ensuring the furnace uniformity, particularly suitable for the sintering of

the lightweight alloy materials.

4. Gas outlet equipped with the aerobic content detection devices, real-time monitoring internal

oxygen content conditions;

5. Mobile workbench, quick and convenient loading and unloading of materials;

6. PC control, data storage and output very easy.

7. Overtemperature, overpressure, overcurrent protection, safe and reliable operation;

Specification

Model	SZF-1100
Chamber size (DWH)	14001400800mm(customized)
Ultimate vacuum	≤500Pa
Heating element	0Cr27Al7Mo2
Temperature measuring element	N-mode thermocouple
Temperature control point	Three point
Temperature control mode	with PID control, self - tuning function , 30 the heating and cooling program
Working temperature	≤1000℃
Max temperature	1000℃
Recommend temperature rising rate	10℃/min
Constant temperature accuracy	±1℃
Pumping rate	70L/S
Rated power	120KW
Power supply	AC380V,50/60HZ
