1400degree C Vacuum tube furnace SGL-1400C
- 300 Set / Sets per Month
- Shanghai
You May Like
-
1200degree C Open type Vacuum tube furnace SKGL-1200C
-
SZGL-1200C Vertical Split Tube Furnaces (VST) for up to 1200.C
-
1100 degree C Electrochemical reaction furnace SGGL-1100
-
1700degree C High and low temperature impact test furnace SHLL-1700
-
falling crucible furnace SSJL-1700
-
1100degree C Multifunctional light alloy melting furnace SRLL-1100
Product Details
Brand Name | SIOMM | Model Number | SGL-1400C | |
Place of Origin | Shanghai, China |
Product Description
Specifications
1) Best value Vacuum tube furnace.2)Single/more/lengthen heating zone tube furnace.
3) KF flange, fast install.
1400degree C Vacuum tube furnace SGL-1400C
SGL - 1400 vacuum tube furnace with imported silicon carbide rode as heating elements, adopted double-shell
structure and intelligent program temperature control system, phase-shift trigger, SCR control, furnace chamber
adopted polycrystalline alumina fiber material. Between double furnace shell equipped with air cooling system
for fast heating and cooling, with vacuum device, can be working in protective gas or vacuum.
1. Adopted KF quick flange sealing, only need a clamp flange the connection can be done. It is veryconvenient to put and take the specimen. Avoiding bolt leakage by artificial operation and reduced the ratio of heating tube damaging which caused by installation flanges;
2. Furnace chamber adopted imported alumina polycrystalline fibers, effective insulation and energy saving. Imported silicon carbide as heating element, greatly improving its service life, high density imported alumina tube, durable use and not easy break;
3. Reserved vacuum, gas road fast interface, could working with our vacuum system or mixed gas system;
4. Reserved 485 convert interface, can be connected with PC through software. It has remote control, real time tracking, history recorder, and output report function. And can be installed the paperless recorder for data storage and output;
5. Built - in thermocouple, real-time monitoring the temperature of the heated material;
6. Optional with the observation window flange, real-time observation of the sintered material conditions;
7. Over-temperature alarm and power failure, leakage protection, safe and reliable operation.
Used for universities, research institutions, industrial and mining enterprises to do high temperature sintering
atmosphere, atmosphere restoring, CVD experimental and vacuum annealing.
Model | SGL-1400 | SGL-1400S |
Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1 | ||
Product feature | No window | Have window |
Furnace chamber | Imported high pure polycrystalline alumina fiber, excellent heat preservation | |
Furnace tube size | Φ60/80/100*1000mm | |
Heating elements | High - quality silicon carbide rod | |
Thermometric component | s-mode thermocouple | |
Temperature control mode | The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 50 the heating and cooling program | |
Seal mode | Stainless steel flange extrusion seal | |
Standard vacuum degree | ≤50Pa (If need more high vacuum degree, can purchase different vacuum system) | |
Working temperature | ≤1300℃ | |
Max temperature | 1350℃ | |
Constant temperature accuracy | ±1℃ | |
Constant temperature zone length | 200mm (Customizable) | |
Max. Temperature rising rate | 15℃/min | |
Recommend temperature rising rate | 10℃/min | |
Rated power | 5KW | |
Working power | AC220V 50HZ/60HZ | |
Overall size | 560*510*740mm | |
Weight | About 80KG | |
Standard accessories | Sealed flanges 1 pcs, O-rings 4 pcs, alumina tube 1 pcs, vacuum pump 1 set, pipe plug 4 pcs, oven gloves, crucible tongs each 1 pcs | |
Optional purchase accessories | Furnace hobs; Mixed gas system; Low, medium and high vacuum system; All kinds of alumina crucibles; Alumina tube or quartz tube; Computer control software; Paperless recorder, etc. |
