Specifications
Configuration features1.Mechanical transmission
2.Mechanical speed change
3.Automatic lifting
4.Automatic feed
Main Features
The radial drilling machine model Z3032 is universal machine, capable of drilling, counterboring, boring, reaming, spot-facing tapping and other similar operations.
It's widely used in machine manufacturing industry for processing small and medium sized machine parts and also suitable for being used in repair shops.
Z3032x9/10 main technical data
SPECIFICATION |
UNIT |
Z3032 x 9/10 |
|
Max. drilling diameter |
mm |
Cast iron32/steel parts27 |
|
Distance between spindle centerline and column generatrix |
mm |
260-680/780 |
|
Distance spindle nose and working surface of base plate |
mm |
220-980/1080 |
|
Spindle travel |
mm |
120/160 |
|
Range of spindle speeds |
r. p. m |
108,162,262,398,665,1000 |
|
Spindle number of feeds |
-- |
6 steps |
|
Overall dimensions((L*W*H) |
mm |
1420*650*2060 |
|
Main motor power |
kw |
1.5/2.2 |
|
N. W/G. W |
kg |
800/900 |
950/1200 |
Main features of Z3050X16 Radial drilling machine :
1. Gather mechanical-electrical-hydraulic functions, use extensively.
2. With wide range of speed and feed, with manual,power and fine feeds.
3. The feed of machines are very easily engaged and disengaged at any time.
4. With safe and reliable feed safety machine, all parts easy operation and change.
5. All controls centralized on the head stock easy operation and change.
6. Clamping for assemblies and speed change of spindle achieved by hydraulic power.
7. Main parts are made by machine center which import form KIA with high precision and efficiency,ensuring reliability and high quality.
8. Integrating technology for casting parts is excellent, adopting casting equipment, ensuring high quality of material for basic parts.
9. Spindle parts are made by special high quality steel heat treatment to be made by first class equipments, ensuring high strength and durability.
10. Main gears are machined by gear grinding, the machine ensuring high precision and low noise.
