Radial Drilling Machine Z3063X20
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HELI
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best-seller Z3050 Radial Drilling Machine With CENegotiableMOQ: 1 Set -
HOT!!High Quality And Low Price Z3050X13/16 Radial Drilling MachineUS$ 1 - 4500MOQ: 1 Set
-
Hot Sale!! High Precision Z3040X10/13 Radial Drilling Machine For Metal ProcessingNegotiableMOQ: 1 Set
-
High Precison Radial Drilling Machine Z3035X10 (ONE YEAR GUARANTEE)NegotiableMOQ: 1 Set
-
Best-seller!!Z3032X10 Radial Drilling Machine With CE CertificatedNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
HELI
Model Number
Z3063X20
Voltage
380V
Rated Power
5.5KW
Dimension(L*W*H)
3000*1200*2400MM
Weight
6500KG
Certification
CE
Warranty
12 months
After-sales Service Provided
Overseas service center available
Specifications
Configuration features1.Hydraulic clamping
2.Hydraulic speed change
3.Hydraulic pre-selection
Z3063X20 main technical data
SPECIFICATION |
UNIT |
Z3063 x 20 |
Max. drilling diameter |
mm |
Cast iron 63 |
Distance between spindle nose and working surface of base plate |
mm |
400-1150 |
Distance between spindle centerline and column generatrix |
mm |
500-2000 |
Spindle travel |
mm |
350 |
Range of spindle speeds |
r.p.m |
25-1100 |
Number of spindle speeds |
--- |
12 |
Range of spindle feeds |
mm/r |
0.06-0.53 |
Number of spindle feeds |
--- |
8 |
Swivel angle of the rocker |
° |
360 |
Main motor power |
kw |
5.5 |
Net weight |
kg |
6500 |
Overall dimensions(L*W*H) |
mm |
3000*1200*2400
|
After-sale Service:
1.Technical support online service provided.
2.Technical files service provided.
3.On-site training service provided.
4.Spare parts replacement and repair service provided.
5.All of the questions will be replied within 24 hours.
