Specifications
1.Mechanical transmission2.Mechanical clamping
3.Mechanical speed change
4.Automatic lifting
5.Automatic feed
Z3040x10/13 main technical data
SPECIFICATION |
UNIT |
Z3040 x 10/13 |
|||
Max. drilling diameter |
mm |
Cast iron 40/steel parts 32 |
|||
Distance between spindle centerline and column generatrix |
mm |
360-1000 |
360-1300 |
||
Distance spindle nose and working surface of base plate |
mm |
260-1050 |
|||
Spindle travel |
mm |
200 |
|||
Range of spindle speeds |
r.p.m |
6 steps 75-1200 |
|||
Spindle number of feeds |
-- |
3 steps 0.10,0.16,0.25 |
|||
Overall dimensions((L*W*H) |
mm |
1500*705*2200 |
1820*840*2420 |
||
Main motor power |
kw |
2.2 |
|||
N.W/G.W |
kg |
1280/1500 |
1330/1900 |
||
Main Features
Main parts and key parts of Z3040x10/13 radial drilling machine are made by high strength cast and special steel material.
Heat treatment made by first-class equipment, ensuring durability.
Machining is made by means of specialized equipment, to ensure basic parts.
Clamping for assemblies and speed-change of spindle is achieved by hydraulic power, and is sensitive and reliable.
6 steps of spindle speed and feed brings about economic and high-efficiency cutting.
Mechanical and electrical controls are centralized on the head stock, with easy and rapid operation.
New painting technology and improved outward appearance reflects the specialty of machines.
Optimum design conforming to international standard.
