Help CenterVertical Milling Machine X5036B
Related Products
-
Vertical and Horizontal Dual-purpose High-speed Milling Machine X6336NegotiableMOQ: 1 Set -
Universal Turret Milling Machine X6332CNegotiableMOQ: 1 Set
-
Milling Machine X6032ZNegotiableMOQ: 1 Set
-
HOT!!X5032 Vertical Milling MachineNegotiableMOQ: 1 Set
-
X6336 Vertical and Horizontal Dual-purpose Milling MachineNegotiableMOQ: 1 Set
Main Characteristics & Application
Model X5036 Vertical Knee-type Milling Machine is suit for milling flat, inclined face, angle surface,
slots by employing disc cutters, angular cutters, formed cutters and face metal milling cutters.
When mounted with the index, the machine will be able to perform milling operations in gears,
Cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ±45°, Spindle quill can be moved in vertical.The longitudinal,
cross and vertical movements of the table can both be operated by hand and power,
and it can be rapid moved. It has the large working table,
a set of cantilever for electric button and a longitudinal handwheel in front of the table,
So the machine can be easy to operate.
Working table and slide ways adopted quality cast hardened ensure high accuracy.
Strong vertical milling machine X5036B main technical data
SPECIFICATIONS |
X5036B |
Spindle taper |
7:24 ISO50 |
Distance from spindle axis to table surface |
60-540mm |
Spindle speed range |
12 steps 60~1700 r.p.m |
Table size |
1500*360mm |
Table travel(longitudinal/cross/vertical) |
1000*320*360mm |
Feed speed range of table longitudinal/cross |
8 steps 12-370mm/min |
X/Y rapid feed speed |
1080mm/min |
Z axis motor power |
1.1KW |
Z axis rapid feed speed |
590mm/min |
Max.weight of table load |
400kg |
T-slot number/width/spacing |
3/18/80mm |
Lifting ram slide way |
Dovetail joint |
Cross slide way |
rectangle |
Longitudinal slide way |
Dovetail joint |
Main motor power |
4KW |
Coolant pump power |
90W |
X,Y axis driving motor |
750W |
Overall dimension |
1700*1680*1880mm |
Net weight |
2280kg |
Quality Guarantee
We will supply enough spare parts and accessories with our machine when shipment. Within one year after receiving our machine, If there are any damaged parts or accessories, We will supply them to you by air-mail .
Our advantages
1 More than fifty years experience of industry products
2,High reputation around the world;
3, Professional service and technology support;
4,Competitive price with better quality, even the best;
Our Service
1, Your inquiry will be replied in 24 hours
2. Our factory has been a Gold supplier continuously in this Alibaba website for 5 years.
And there is more industry technology experience for 56 years with our factory
3, To offer free spare parts and service within one year of warranty
4, Professional after-sales service team
5,Give reasonable offers with the best quality
