Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > Ecconomic Horizontal Manual GAP Lathe Hot-sale CDE6250

Ecconomic Horizontal Manual GAP Lathe Hot-sale CDE6250

Name: Ecconomic Horizontal Manual GAP Lathe Hot-sale CDE6250
Brand: DALIAN
SKU: 102718995
Availability: InStock

Ecconomic Horizontal Manual GAP Lathe Hot-sale CDE6250 thumbnail-1

Ecconomic Horizontal Manual GAP Lathe Hot-sale CDE6250 photo-1

US$ 5,075 - 32,230 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 320~1000mm

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number CDE6240; CDE6250; CDE6266

Voltage 220V,380V,415V,440V,480V;

Power(W) 7.5/11kW;

Certification ISO9001:2008; GB/T19001:2008

After-sales Service Provided Engineers available to service machinery overseas

Horizontal GAP Lathe Technical Specification

(For more information, to: export(at)longlife-machinery(dot)com)

It can machine inner circle, outer circle, and end & head surface, taper surface. Gap lathe can process the deformation parts. Function includes the drilling and reaming. Metric, inch, diametrical pitch, module thread.The bed is made of high-grade cast iron. The bed is undergoing surface quenching, the hardness can be HRC50.The noise can be under 83(A).

Item	CDE6240A	CDE6250A	CDE6266A
Max. swing over bed (mm)	Φ400	Φ500	Φ660
Max. swing over carriage (mm)	Φ220	Φ290	Φ430
Max. swing over gap (mm)	Φ700	Φ760	Φ910
Max. length of work piece(mm)	750/1000/1500/2000/3000
Width of guide way (mm)	394
Dia. of spindle bore (mm)	Φ 52
Taper of center sleeve (Morse)	No.6
Spindle speed (rpm)	11~1400/22
Longitudinal feed(rpm)	0.035~2.842
Cross feed (rpm)	0.009~0.804
Metric thread(mm)	0.5~240(66)
Inch thread(tpi)	80~1/4(49)
Module thread(mm)	0.25~120(57)
Diametrical pitch thread(DP)	160~7~16DP(50)
Section of tool shank(mm)	25×25
Travel of top slide(mm)	150
Max. travel of cross slide(mm)	348/ 348/393
Pitch of longitudinal lead screw(mm)	12
Travel of tailstock center sleeve(mm)	150
Diameter of tailstock center sleeve(mm)	75
Taper of tailstock center sleeve	Morse No.5
Main motor power	7.5kW(50Hz)/5.5kW(60Hz)
Wooden case(mm)	2950x1150x1900
Gross/net weight(kg)	2715/2020 2765/2070 2873/2178
