CW61140Mx3000 Heavy Duty Horizontal Lathe

CW61140Mx3000 Heavy Duty Horizontal Lathe thumbnail-1
CW61140Mx3000 Heavy Duty Horizontal Lathe photo-1
US$ 4,500 - 32,230 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Long Life Machinery Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not Normal
Automatic Grade Manual
Max. Swing Diameter 1400mm
Place of Origin Liaoning, China
Brand Name DALIAN
Model Number CW61140Mx3000 heavy duty horizontal lathe
Voltage 220V,380V,415V,440V,480V;
Power(W) 22kW
Certification CE; ISO9001:2008; GB/T19001:2008
After-sales Service Provided Engineers available to service machinery overseas



Main Features

Compound sliding plate is provided, so parts in taper can be turned;

Standard spindle head: A2-15, spindle bore: 130mm

Headstock contains hydraulic clutch and hydraulic brake

Guide rail width:750mm

Largest load capacity between 2 core clamper (with steady rest): up to 5000kg

Order notice must be specified with: condition of installed taper imitated shape device

Guide rail hardness:HRC50, Depth1.5mm

Only provide left-hand wheel

Vertical and horizontal rapid shift handle for slide board boxes

Tailstock sleeve with a dividing rule should be specially annotated.

Main Technical Data

Specifications

Unit

Parameter

Swing over Bed

mm

1400

Max length of work piece

mm

3000

Swing in Gap

mm

1800

Width of Gap

mm

600

Width of Guide way

mm

755

No. of Spindle Speed Ranges



21

Spindle Speed

mm/min

3.15~315

Spindle Bore

mm

130

Spindle Nose



D13

Longitudinal Feed

mm/rev

0.1~12

Cross Feed

mm/rev

0.05~6

Metric Thread

mm

1~120

Module Thread

mm

0.5~60

Whitworth Thread

TPI

28~1/4

Diametrical Thread

DP

1/2~56

Max. Travel of Top Slide

mm

300

Main Motor Power

kW

22

Cross weight

kg



Net weight

kg



Bottom size of metal packing

cm
