CW6263x3000 Universal Horizontal Lathe With GAP

CW6263x3000 Universal Horizontal Lathe With GAP thumbnail-1
CW6263x3000 Universal Horizontal Lathe With GAP photo-1
US$ 18,900 - 19,147 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Horizontal
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Long Life Machinery Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Horizontal
CNC or Not Normal
Automatic Grade Manual
Max. Swing Diameter 1000mm
Place of Origin Liaoning, China
Brand Name DALIAN
Model Number CW6263Ex3000
Voltage 220V,380V,415V,440V,480V; 50/60Hz
Power(W) 11/15kW;
Dimension(L*W*H) 5380x1100x1650mm
Weight 4650kgs
Certification CE; ISO9001:2008; GB/T19001:2008
After-sales Service Provided Engineers available to service machinery overseas
CW6263x3000 Universal Horizontal Lathe with GAP

Main Usage

such universal metal lathe has following functions:

  • It can machine inner circle, outer circle, and end and head surface, taper surface;
  • Gap lathe can process the deformation parts;
  • Function is including the drilling and reaming;
  • Metric, inch, diametrical pitch, module thread;
  • The bed is made of high-grade cast iron;
  • The bed is undergoing surface quenching, the hardness can be HRC50;
  • The noise can be under 83(A);
CW6263x3000 Universal Horizontal Lathe with GAP

Main Technical Data

Specifications

Unit

Parameter

Max. swing over bed

mm

630

Max. swing over carriage

mm

350

Center distance

mm

3000

Width of gap

mm

320

Swing over gap

mm

800

Width of guide way

mm

550

Spindle bore diameter

mm

105/130 opt

spindle nose



C11/D11 opt

Spindle speed

rpm

(18 speeds) 7.5~1000

Longitudinal feed

mm/r

(64) 0.1~24.3

Cross feed

mm/r

(64) 0.05~12.15

Rapid traverse speed

m/min

3.8

Metric thread

mm

(39)1~240

Inch thread

TPI

(26) 14~1

Module thread

mm

(53) 0.5~120

Diametrical pitch thread

D.P

(24) 28~1

Max. travel of cross slide

mm

493

Travel of top slide

mm

200

Main motor power

kW

11

Rapid traverse motor power

kW

1.1

Coolant pump motor power

kW

0.09

Wooden box

mm

5460×1150×1890

Pallet packing

mm

5380×1100×1650

Gross/Net weight

kg

6250/4650
Free Std Accessories

Name

Size(mm)

3-jaw chuck

 Φ320(For CW6263E)

4-jaw chuck

Φ500(For CW6263E)

Steady rest

Φ20~Φ170(For CW6263E)

Follow rest

Φ20~Φ100(For CW6263E)

Dead center

2 sets

Reducing sleeve

1 set

Wrench Tool

1 set

Oil gun

1 set

Instruction Manual

1 set

Certificate of Conformity

1 set

Packing List

1 set

Manual for Spare Parts

1 set
Auto Production Line

CW6263x3000 Universal Horizontal Lathe with GAP

CW6263x3000 Universal Horizontal Lathe with GAP

CW6263x3000 Universal Horizontal Lathe with GAP

CW6263x3000 Universal Horizontal Lathe with GAP
