JAC ELECTRIC FORKLIFT CPD30(DC Motor)

JAC ELECTRIC FORKLIFT CPD30(DC Motor) thumbnail-1
JAC ELECTRIC FORKLIFT CPD30(DC Motor) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
JAC
Contact Supplier Request Quote Chat Now
Shandong Sea Project Machinery Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Anhui, China
Brand Name JAC
Model Number CPD30
Power Souce DC Motor
Rated Loading Capacity 3T
Max. Lifting Height 3000
Min. Lifting Height 155
Fork Length 1070
Fork Width 125





          Model Units CPD10 CPD15 CPD20 CPD25 CPD30
Load Capaciry  Kg 1000 1500 2000 2500 3000
Load Center  mm 500
Max. lifting height mm 3000
Free Lift  mm 125 160 155
Tillifing  Angles Front    6°
Rear    12°
Max. lifting height Without Load mm/s 300 430 427 360
With Load mm/s 235 272 257 280
Max. drop speed Without Load mm/s ≥300
With Load mm/s ≤600
Max Gradeability (With Load)   15 15 10 10 12
Min. Turning Radius mm 1950 1950 2300 2320 2250
Weight  Kg 2600 2900 4150 4460 4960
Form Size Overhead Length without fork mm 1975 1980 2360 2390 2565
with fork mm 2895 2900 3325 3460 3635
Overhead Widt Outboard mm 1070 1180 1255
Frame mm 1070 1150 1225
Height Mast drop mm 1995 1990 2065
Front-wheel Overhead  mm 2080 2180 2200
Turning Radius Mast underside mm 105 80 84 125
Frame middle mm 110 125 130 140
Wheelbase mm/s 1250 1500 1600
Tread Fornt mm 890 980 1000
Back mm 920 950 970
Overhang (front) mm 410 485 498
Overhang (back) mm 319 349 395 425 /
  Inside cab seat height mm 1015
axle charge Driving axle With Load Kg 2995 3880 5320 6025 /
Without Load Kg 1251 1290 1675 1725 /
turning wheel With Load Kg 570 540 830 935 /
Without Load Kg 1313 1580 2475 2735 /
Tire  Driving wheel Specs   6.50-10-10PR 7.00-12-12PR
Air pressure Pa 700000
turning wheel Specs   5.00-8-10PR 18×7-8 18×7-8-14PR
Air pressure Pa 700000
 Battery Voltage V 48 80
Capacity AH 400/480 620 620 500
 Motor  running Model   XQ-5T XQ-8-1T XQ-10-T
Rating power KW 5 8 10
 Fork Size(L*W*T) mm 920×100×31 920×100×35 920×122×40 1070×122×40 1070×125×45







JAC ELECTRIC FORKLIFT CPD30(DC Motor)JAC ELECTRIC FORKLIFT CPD30(DC Motor)



HAIG is one of the top construction equipment providers in China. Being the type of "Industry and trade in one", we are committed to offer our respectable customer high quality products with reliable performance ,competitive price and sincere services



WE LOOK FORWARD TO COOPERATE WITH YOU!

JAC ELECTRIC FORKLIFT CPD30(DC Motor)



IF ANY NEW INQUIRY,PLS DON'T HESITATE TO CONTACT ME.



JAC ELECTRIC FORKLIFT CPD30(DC Motor)
