Help CenterHW220 Excavator
Related Products
Specifications
Excavator HW220,Haig BrandBucket Capacity:1cbm
Operating Weight:21600kgs
Engine:Cummins B5.9-C
Digging Depth:6.605mm
Model |
HW220 |
||
Bucket capacity |
m³ |
1 |
|
Standard bucket width |
mm |
1160 |
|
Operating weight |
kg |
2,1600 |
|
Dimension (in transportation) |
Overall length |
mm |
9,548 |
Overall width |
mm |
2,880 |
|
Overall height |
mm |
2,977 |
|
Min. ground clearance |
mm |
470 |
|
Engine |
Model |
Cummins B5.9-C |
|
Total displacement |
L |
5.9 |
|
Rated output power |
KW/rpm |
112/1950 |
|
Digging performance |
Max. digging height |
mm |
9,281 |
Max. dumping height |
mm |
6,480 |
|
Max. digging depth |
mm |
6,605 |
|
Max. vertical digging depth |
mm |
5,735 |
|
Max. digging radius |
mm |
9,845 |
|
Boom deflection angle: left/right |
° |
|
|
Min. slew radius |
mm |
3,500 |
|
Min. rear slew radius |
mm |
2,853 |
|
Bucket digging force |
kn |
115 |
|
Track type |
Steel |
||
Track width |
mm |
600 |
|
Travel system |
Track overall length |
mm |
4,237 |
Wheel base |
mm |
3,450 |
|
Track gauge |
mm |
2,280 |
|
Travel speed (Gear Ⅰ/Ⅱ) |
km/h |
5.4/3.3 |
|
Gradeability |
% |
70 |
|
Slew speed |
rpm |
11.9 |
|
Bulldozing plate |
Bulldozing plate (width) |
mm |
|
Bulldozing plate (height) |
mm |
|
|
Lifting distance (GL up/down) |
mm |
|
|
Hydraulic pump type |
Piston pump×2 |
||
Fuel tank capacity |
L |
360 |
|
Hydraulic oil tank capacity |
L |
250 |
|
