JAC ELECTRIC FORKLIFT (1~3TONS) WITH XINCHAI ENGINE

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port TIANJIN/SHANGHAI
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New		Place of Origin	Anhui, China
Brand Name	JAC		Power Souce	Diesel Engine

Product Description

Model				Units	CPD10	CPD15	CPD20	CPD25	CPD30
Load Capaciry				Kg	1000	1500	2000	2500	3000
Load Center				mm	500
Max. lifting height				mm	3000
Free Lift				mm	125		160		155
Tillifing Angles			Front		6°
			Rear		12°
Max. lifting height			Without Load	mm/s	300		430	427	360
			With Load	mm/s	235		272	257	280
Max. drop speed			Without Load	mm/s	≥300
			With Load	mm/s	≤600
Max Gradeability (With Load)					15	15	10	10	12
Min. Turning Radius				mm	1950	1950	2300	2320	2250
Weight				Kg	2600	2900	4150	4460	4960
Form Size	Overhead Length	without fork		mm	1975	1980	2360	2390	2565
		with fork		mm	2895	2900	3325	3460	3635
	Overhead Widt	Outboard		mm	1070		1180		1255
		Frame		mm	1070		1150		1225
	Height	Mast drop		mm	1995		1990		2065
		Front-wheel Overhead		mm	2080		2180		2200
Turning Radius			Mast underside	mm	105		80	84	125
			Frame middle	mm	110		125	130	140
Wheelbase				mm/s	1250		1500		1600
Tread			Fornt	mm	890		980		1000
			Back	mm	920		950		970
Overhang (front)				mm	410		485		498
Overhang (back)				mm	319	349	395	425	/
Inside cab seat height				mm	1015
axle charge	Driving axle	With Load		Kg	2995	3880	5320	6025	/
		Without Load		Kg	1251	1290	1675	1725	/
	turning wheel	With Load		Kg	570	540	830	935	/
		Without Load		Kg	1313	1580	2475	2735	/
Tire	Driving wheel	Specs			6.50-10-10PR		7.00-12-12PR
		Air pressure		Pa	700000
	turning wheel	Specs			5.00-8-10PR		18×7-8		18×7-8-14PR
		Air pressure		Pa	700000
Battery		Voltage		V	48				80
		Capacity		AH	400/480		620	620	500
Motor running		Model			XQ-5T		XQ-8-1T		XQ-10-T
		Rating power		KW	5		8		10
Fork Size(LWT)				mm	920×100×31	920×100×35	920×122×40	1070×122×40	1070×125×45

Our company can provide you high quality forklift with best price and professional service.We have our sales,service and accessory team. Our products have exported to many countries,such as Mid East,South America, Aisa.Hope to cooperate with you in the near future.
