Semi-Electric Aerial Order Picker
US$ 3,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Olift
Model Number:
TH
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Portable Aluminum Alloy Work PlatformUS$ 500 - 2,000MOQ: 1 Unit -
Aerial Electric Order PickerNegotiableMOQ: 1 Set
-
6-12m 300kg Electric Mobile Scissor LiftUS$ 1,000 - 3,000MOQ: 1 Set
-
1 - 8m Wheelchair Lift For Disabled People / Home Use Small ElevatorUS$ 1,500 - 4,500MOQ: 1 Unit
-
14m Articulating Boom Lift RTBZ16ANegotiableMOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
Olift
Model Number
TH
Lift Mechanism
Lift Chain
Lift Drive / Actuation
Electric Motor
Power
1.5kw
Rated Loading Capacity
200kgs
Min. Lifting Height
30mm
Max. Lifting Height
2.7m,3.3m,3.5m,4m,4.5m
Table Size
900*600 mm
Weight
600-675kgs
Certification
CE SGS ISO
Warranty
1 Year
After-sales Service Provided
Overseas third-party support available
Semi-Electric Aerial Order Picker
Product Description
Semi-Electric Aerial Order Picker-TH Series
1. Our aerial order picker is electrically lift and manually pushed
2. Adopt imported Winner hydraulic pump station
3. Equipped with maintenance-free battery
4. No noise and pollution during operation
5. Applied for picking and placing small items
6. The product can be powered by DC.
TH Specifications:
| Model No. | TH0227 | TH0233 | TH0235 | TH0240 | TH0245 | |
| max.platform height | mm | 2700 | 3300 | 3500 | 4000 | 4500 |
max.machine height |
mm | 4700 | 5300 | 5500 | 6000 | 6500 |
| ground clearance | mm | 30 | 30 | 30 | 30 | 30 |
| lift rated capacity | kg | 200 | 200 | 200 | 200 | 200 |
| platform size | mm | 600*950 | 600*950 | 600*900 | 600*900 | 600*900 |
| battery | V/Ah | 12/120 | 12/120 | 12/120 | 12/120 | 12/120 |
| charger | V/A | 12/15 | 12/15 | 12/15 | 12/15 | 12/15 |
| lifting motor | V/kw | 12/1.5 | 12/1.5 | 12/1.5 | 12/1.5 | 12/1.5 |
| overall length | mm | 1300 | 1300 | 1300 | 1300 | 1300 |
| overall width | mm | 760 | 840 | 840 | 840 | 840 |
| overall height | mm | 1760 | 2040 | 1660 | 1830 | 1990 |
| overall net weight | kg | 268 | 313 | 265 | 315 | 365 |
