2.5tons 3tons 5 tons Hydraulic Hand Pallet Jack
Pallet Truck
1.Load-in/lead-out rollers under the fork tips enable pallets to be entered any kind of pallet
2.No routine maintenance at all is needed on the hydraulics unit and bearings
3.Important seals made in Germany, which prolong the working time of hydraulic unit
4. Specially designed to lift and transport the widest variety ofloads in stores and warehouse
Features:
1.Key components of the fully sealed oil pump are from Germany, solving the oil leakage problem.
2.the soild chromeplated piston rod has overloading protection, which can control the descent speed.
3.Valve plug is an integral piece, easy to maintain.
4.Movement parts of our hand pallet truck are applied with alloy bush, which is wear resistant and easy to replace.
Specification:
| Model No. | A100 | A101 | A102 | ||||||
| Capacity | kg | 2000 | 2500 | 3000 | |||||
| Min. fork height h | mm | 85 | 75 | 85 | 75 | 85 | 75 | ||
| Max. fork height h1 | mm | 200 | 190 | 200 | 190 | 200 | 190 | ||
| Steering wheel | mm | Φ200x50 | Φ180x50 | Φ200x50 | Φ180x50 | Φ200x50 | Φ180x50 | ||
| Load roller Single | mm | Φ82x93 | Φ74x93 | Φ82x93 | Φ74x93 | Φ82x93 | Φ74x93 | ||
| Load roller Tandem | mm | Φ82x70 | Φ74x70 | Φ82x70 | Φ74x70 | Φ82x70 | Φ74x70 | ||
| Size of fork | mm | 160x50 | 160x60 | ||||||
| Width overall forks | mm | 450/520/540/685 | |||||||
| Fork length | mm | 800/900/1100/1150/1220 | |||||||
| Packaging Detail: | hand pull trolley will be packed by Flexible Package, Seaworthy Package. |
| Delivery Detail: | 7-10 days for hydraulic pump hand pull trolley |
1.Our company has passed ISO9001 and our products has passed CE andSGS.
2.We offer technical supporting all year round.If you want to get more details,please visit or website:
Company Profile:
Olift Equipment Co.,Ltd. provides wide selection of products such as forklift trucks, pallet trucks and stackers, scissor lifts, moving tools, platform lifting and more.
The workforce engages in intense research to develop functional, easy-to-use products that can provide the clients total value for their investment. The company emphasizes on total customer satisfaction, thus all equipment are manufactured to international standard and with impeccable quality.
In addition, it has in-house technical capabilities to design and manufacture the equipment. Strict quality management is applied throughout all stages of production process to ensure the precision and high performance of products.
