Olift 2.0 Ton Electric Cold Storage Type Forklift With CE

Olift 2.0 Ton Electric Cold Storage Type Forklift With CE thumbnail-1
Olift 2.0 Ton Electric Cold Storage Type Forklift With CE photo-1
US$ 13,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
Olift
Contact Supplier Request Quote Chat Now
Qingdao Olift Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin China
Brand Name Olift
Model Number FB
Power Souce DC Motor
Rated Loading Capacity 1600-3000 kg
Max. Lifting Height 3000-6000 mm
Min. Lifting Height 40 mm
Fork Length 1070 mm
Fork Width 570 mm
Overall Dimensions 3200*1100*2200 mm
Certification CE,SGS,ISO
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Olift 2.0ton Electric cold storage type forklift with CE
1.High stability and safety
2.Economics
3.Easy maintenance

Olift 2.0 ton Electric cold storage type forklift with CE





Product Description

 FB Series electric forklift is a smart design for refrigeration house material handling.

1.We have different design on capacity from 1600kgs to 3000kgs maximum for different demand of material weight.

2.While for stacking height, it could satisfy your request from 3m to 6m, you could handle with your loading, moving or stacking works easily with it.

3.With 2350 turing radius, you could easily move it in refrigeration house. A special feature of FB is that, he could steering with single point.

New design,New product,New Experience.



FB Specifications:

model FB16/FB16A FB18/FB18A FB20/FB20A FB25 FB25A FB30
capacity kg 1600 1800 2000 2500 2500 3000
lifting height mm 3000-6000 3000-6000 3000-6000 3000-6000 3000-6000 3000-6000
load center distance mm 500 500 500 500 500 500
fork rack width mm 1088 1088 1088 1160 1160 1200
height of overhead guard mm 2015-2610 2015-2610 2015-2610 2040-2654 2040-2654 2070-2684
height mast extened mm 4067-7067 4067-7067 4067-7067 4067-7067 4067-7067 4250-7250
fork length mm 2135 2135 2135 2380 2585 2585
overrall width mm 1100 1100 1100 1150 1150 1205
overrall length mm 3205 3205 3205 3450 3655 3655
min.turning radius mm 1900 1900 1900 2150 2350 2350
max.speed (laden/unladen) km/h 0~15 0~15 0~13.5 0~13.5 0~13.5 0~13
lifting.speed (laden/unladen) m/s 300 280 270 260 260 220
lifting.speed (laden/unladen) m/s <600 <600 <600 <600 <600 <600
max. travel grade (laden/unladen) % 15 15 15 13 13 13
driving motor kw 5 5 7 7 7 10.2
lifting motor kw 8.2 8.2 8.2 8.6 8.6 10
aneroid battery v/ah 48/450 48/450 48/450 48/630 48/630 80/450
net weight kg 3050 3150 3280 4050 4150 4350







 Olift 2.0 ton Electric cold storage type forklift with CEOlift 2.0 ton Electric cold storage type forklift with CEOlift 2.0 ton Electric cold storage type forklift with CEOlift 2.0 ton Electric cold storage type forklift with CE
