Chinese forklift Good Quality Japanese engine diesel forklifts with automatic transmission
A reliable mast :
- Emphasis on the inherent quality of the mast has provided operatoe a reliable security. Wide view mast makes vision more clearly.
- we adopted the German mast channel which has the world-class quality.
- The cross-section of mast channel has been increased and the structure become more strong.
New type of adjusting mechanism of the steering:
- The new type steering wheel dual threaded adjustment mechanism with patented technology has improved the operator comfort and adjustment reliability
New drive and control system :
- Adopt the international electric actuators and makes the truck steering more stable,and output power stronger.
- New electronic blanker improves the comfort and safety of the operation.
Model |
DF20 |
|
DF25 |
|
DF30 |
|
DF35 |
|
|
Load capacity kg |
2000 |
2500 |
3000 |
3500 |
|||||
Load center mm |
500 |
500 |
500 |
500 |
|||||
Power type |
Diesel |
||||||||
Max.lifting speeds(with load)mm/s |
400 |
400 |
400 |
390 |
|||||
Max.Driving speeds(with without load)km/h |
17/19 |
17/19 |
18/20 |
17/19 |
|||||
Max.Towing speeds(with/without load)kN |
14/9 |
15/10 |
15.5/10.5 |
16/11 |
|||||
Gradeability(with/without load)% |
15/20 |
15/20 |
15/20 |
15/20 |
|||||
H1 Lifting height mm |
3000 |
4000 |
3000 |
3000 |
|||||
Tilting angles(forward-backward) . |
6/12 |
6/12 |
6/12 |
6/12 |
|||||
Min. turning radius mm |
2400 |
2425 |
2980 |
2575 |
|||||
Min. right angle aisle width mm |
2090 |
2115 |
2750 |
2180 |
|||||
Min. under-clearance mm |
110 |
110 |
125 |
125 |
|||||
Dimensions |
A Overall length (inincluding fork) mm |
3485 |
3510 |
3810 |
3835 |
||||
B Overall width mm |
1160 |
1160 |
2100 |
1230 |
|||||
H Overall height(mast lowered) mm |
2190 |
2550 |
2230 |
2230 |
|||||
H2 Overall height(mast extend) mm |
4080 |
4080 |
4270 |
4270 |
|||||
H3 Overall height to overhead guard mm |
2165 |
2165 |
2190 |
2190 |
|||||
A1 Fork overhang mm |
450 |
450 |
490 |
490 |
|||||
A2 Wheel base mm |
1640 |
1640 |
1750 |
1750 |
|||||
Tread |
B1 Front tread mm |
970 |
970 |
1000 |
1000 |
||||
B2 Rear tread mm |
970 |
970 |
970 |
970 |
|||||
Tyre |
Front tyre |
7.00-12 |
7.00-12 |
28×9-15 |
28×9-15 |
||||
Rear tyre |
6.00-9 |
6.00-9 |
6.50-10 |
6.50-10 |
|||||
Total weight kg |
3320 |
3600 |
4950 |
4550 |
|||||
B3 Fork width mm |
122 |
122 |
125 |
125 |
|||||
H4 Fork thickness mm |
45 |
45 |
45 |
45 |
|||||
Backrest height mm |
1000 |
1000 |
1225 |
1225 |
|||||
A3 Fork length mm |
900(1070) |
900(1070) |
1070 |
1070(1200) |
|||||
Engine |
Engine model |
490BPG(A490BPG) |
490BPG(A490BPG) |
490BPG(A490BPG) |
495BPG(495BPG) |
||||
Rate power KW |
36.8 |
36.8 |
36.8 |
37.6 |
|||||
Rotate Speed At Rate Power rpm |
2650 |
2650 |
2650 |
2780 |
|||||
Max.torque Nm |
≥148 |
≥148 |
≥148 |
≥152 |
|||||
Rotate speed at max torque rpm |
1800-1900 |
1800-1900 |
1800-1900 |
2000-2100 |
|||||
Type of power shift |
Clutch |
Tor-con |
Clutch |
Tor-con |
Clutch |
Tor-con |
Clutch |
Tor-con |
|
| Packaging Detail: | forklifts with automatic transmission will be packed by Flexible Package, Seaworthy Package. |
| Delivery Detail: | 15-30 days for forklifts with automatic transmission |
1.Our company has passed ISO9001 and our products has passed CE andSGS.
2.We offer technical supporting all year round.If you want to get more details,please visit or website:
Company Profile:
Olift Equipment Co.,Ltd. provides wide selection of products such as forklift trucks, pallet trucks and stackers, scissor lifts, moving tools, platform lifting and more.
The workforce engages in intense research to develop functional, easy-to-use products that can provide the clients total value for their investment. The company emphasizes on total customer satisfaction, thus all equipment are manufactured to international standard and with impeccable quality.
In addition, it has in-house technical capabilities to design and manufacture the equipment. Strict quality management is applied throughout all stages of production process to ensure the precision and high performance of products.
