As a leading manufacturer in the environmental technology sector, Qingdao Conqinphi Environmental Technology Group Co., Ltd. is proud to present our Compact Forced Circulation Evaporator – a precision-engineered solution designed specifically for laboratory-scale concentration and evaporation tasks. With a robust 304 stainless steel construction, a processing capacity of 50 L/h, and reliable 220V operation, this evaporator delivers consistent performance and exceptional durability. Whether you are developing new formulations, conducting pilot studies, or optimizing existing processes, this compact unit offers the versatility and efficiency your lab demands.
Our forced circulation design ensures uniform heat transfer and minimizes scaling, even when handling viscous or heat-sensitive materials. The system is built to meet the highest standards of quality and safety, backed by our ISO9001, HACCP, and other international certifications. With over 10 years of manufacturing experience and a factory spanning 10,000–30,000 square meters, we have the expertise and resources to support your laboratory needs.
Below you will find detailed specifications, key features, and answers to frequently asked questions about this product.
Key Features
- Forced Circulation Technology: A dedicated pump ensures continuous recirculation of the process fluid, enhancing heat transfer coefficients and reducing evaporation time by up to 30% compared to natural circulation systems.
- 304 Stainless Steel Construction: All wetted parts are made from high-quality 304 stainless steel, providing excellent corrosion resistance and compatibility with a wide range of chemicals, including acids, alkalis, and solvents.
- Compact, Space-Saving Design: The bench-top footprint (approx. 600 mm × 400 mm × 800 mm) makes it ideal for laboratories with limited space, while still delivering a substantial evaporation capacity of 50 L/h.
- User-Friendly Operation: Simple manual controls allow for precise adjustment of feed flow rate, temperature, and circulation speed. An optional automated control panel can be added for advanced process monitoring.
- Energy Efficiency: The system operates at 220V/50–60Hz with a moderate power consumption of approximately 2.5 kW, reducing operational costs without compromising performance.
- Safety Features: Equipped with over-temperature protection, pressure relief valve, and emergency stop button to ensure safe operation in laboratory environments.
Technical Specifications
| Parameter | Value |
| Material | 304 Stainless Steel |
| Evaporation Capacity | 50 L/h (at optimum conditions) |
| Power Supply | 220V, 50/60Hz, single phase |
| Heating Method | Electric heating or steam (customizable) |
| Operating Temperature | Up to 120°C (adjustable) |
| Circulation Pump | Centrifugal, 0.5 HP, 304 SS |
| Dimensions (L×W×H) | 600 × 400 × 800 mm |
| Net Weight | Approx. 45 kg |
| Control Type | Manual (automatic optional) |
Benefits for Your Laboratory
- Accelerated Process Development: The forced circulation mechanism allows rapid concentration and solvent recovery, enabling faster iteration in formulation studies.
- Product Quality Preservation: Gentle heating and efficient circulation minimize thermal degradation, maintaining the integrity of heat-sensitive compounds.
- Reduced Maintenance: 304 stainless steel is easy to clean and resistant to fouling, decreasing downtime between batches.
- Scalability: Data obtained from this lab-scale unit can be reliably used to design larger production-scale forced circulation evaporators, thanks to consistent hydrodynamic principles.
- Global Compliance: Our manufacturing processes conform to ISO9001, HACCP, and other international standards, ensuring that the equipment meets the regulatory requirements of your region.
At Qingdao Conqinphi, we have been serving customers worldwide since 2015. Our annual export value exceeds US$10 million, and we have shipped our products to North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. Our team of 201–300 skilled professionals is dedicated to continuous improvement and customer satisfaction. We are proud to hold certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and several others, demonstrating our commitment to quality, environmental responsibility, and workplace safety.
This Compact Forced Circulation Evaporator is a testament to our engineering excellence. It is rigorously tested before shipment and comes with a comprehensive warranty and after-sales support. Whether you are a research institute, a university lab, or a pilot plant, this evaporator will help you achieve your evaporation goals efficiently and reliably.
Contact us today to discuss your specific requirements or to request a quotation. Our technical team is ready to assist you with customization options, such as different heating sources, automation levels, or additional accessories.
Frequently Asked Questions
-
Q: What is the maximum operating temperature of this evaporator?
A: The standard unit can operate up to 120°C. For higher temperature requirements, a customized version with enhanced heating elements is available upon request. -
Q: Can this evaporator handle viscous liquids like syrups or slurries?
A: Yes, the forced circulation design is particularly effective for viscous materials. The pump is selected to handle fluids up to 5000 cP. For extremely high viscosities, please consult our engineering team for a tailored solution. -
Q: Is the system easy to clean between batches?
A: Absolutely. The 304 stainless steel surfaces are smooth and non-porous, and the compact design allows easy access to all wetted parts. A clean-in-place (CIP) option can be integrated as an upgrade. -
Q: What safety features are included?
A: The evaporator includes over-temperature protection, a pressure relief valve, an emergency stop button, and a leak detection system. All electrical components are IP54 rated for protection against dust and splashes. -
Q: Do you provide installation and training support?
A: Yes, we offer remote installation guidance and on-site training for domestic clients. For international customers, we provide detailed manuals, video tutorials, and online technical support. A paid on-site service option is also available. -
Q: What is the typical lead time for this product?
A: Standard models can be shipped within 15–20 working days after order confirmation. Customized versions may require 30–45 working days depending on the modifications. -
Q: Can the evaporator be used for solvent recovery?
A: Yes, it is commonly used for recovering solvents like ethanol, acetone, and water. For flammable solvents, an explosion-proof version with ATEX-certified components is available as an option. -
Q: What warranty do you offer?
A: We provide a 12-month warranty covering manufacturing defects. Extended warranty plans are available for purchase. Our after-sales service team is available 24/7 for urgent inquiries.
