Help CenterLarge Capacity Forced Circulation Evaporator for Chemical Concentration
Product Spotlights
Related Products
-
Compact Forced Circulation Evaporator With CIP Cleaning SystemUS$ 54300 - 829000MOQ: 1 Combo -
Forced Circulation Evaporator for Pharmaceutical Crystallization ProcessesUS$ 54300 - 829000MOQ: 1 Combo
-
Customizable Forced Circulation Evaporator for Food Grade ApplicationsUS$ 54300 - 829000MOQ: 1 Combo
-
Forced Circulation Evaporator With 1-Year Warranty and Technical SupportUS$ 54300 - 829000MOQ: 1 Combo
-
Standard Compliant Forced Circulation Evaporator for Solvent RecoveryUS$ 54300 - 829000MOQ: 1 Combo
As a leading manufacturer specializing in advanced separation and concentration solutions, Qingdao Conqinphi Environmental Technology Group is proud to introduce our high-performance Large Capacity Forced Circulation Evaporator. Engineered for demanding chemical concentration processes, this system is designed to deliver exceptional efficiency, reliability, and scalability for industrial operations. With our extensive experience and modern manufacturing facilities spanning over 10,000 square meters, we provide robust equipment that meets the rigorous demands of global markets, from North America and Europe to Southeast Asia and beyond. Our commitment to quality, backed by a comprehensive management system, ensures that every evaporator is built to optimize your production and maximize your return on investment.
This Forced Circulation Evaporator is specifically engineered to handle high-viscosity, scaling, or crystallizing fluids common in chemical processing. Its core principle involves the forced recirculation of the liquid through a heat exchanger and a separation chamber, which significantly enhances heat transfer rates and prevents fouling. This design is ideal for concentrating solutions where natural circulation is insufficient.
Key Features & Technical Advantages:
- High Thermal Efficiency: The forced circulation mechanism creates high fluid velocity across the heating surface, minimizing boundary layer resistance and maximizing heat transfer coefficients.
- Anti-Scaling & Anti-Fouling Design: The high flow rate helps prevent solids from depositing on the heat transfer surfaces, making it suitable for solutions prone to scaling or containing suspended crystals.
- Large Processing Capacity: Designed for continuous, high-throughput operations, this unit can handle substantial feed volumes, making it perfect for large-scale chemical production plants.
- Flexible Material Options: Constructed primarily from high-grade stainless steel (SS304 or SS316/L), with other materials like titanium or duplex steel available upon request for corrosive applications.
- Adaptable Heat Source: Compatible with various heating mediums including plant steam, thermal oil, or electricity, allowing for integration into diverse existing plant utilities.
- Advanced Control Systems: Optional PLC-based automation ensures precise control over parameters like temperature, pressure, flow rate, and density, leading to consistent product quality and reduced manual intervention.
- Energy-Saving Configurations: Can be designed as a multi-effect system or integrated with a Mechanical Vapor Recompression (MVR) unit to drastically reduce steam consumption and operational costs.
Technical Specifications Overview:
| Parameter | Typical Range / Description |
| Evaporator Type | Forced Circulation |
| Primary Application | Concentration of Chemical Solutions |
| Capacity (Evaporation Rate) | Customizable from several tons to over 50 tons per hour |
| Heating Surface Area | Designed based on client's capacity and thermal requirements |
| Operating Pressure | Atmospheric, Vacuum, or Positive Pressure operation available |
| Material of Construction (Standard) | SS304 / SS316L Stainless Steel |
| Heat Source | Steam, Thermal Oil, Electric Heating |
| Control System | Manual, Semi-Automatic, or Full PLC Automation (Optional) |
Benefits for Your Operation:
- Increased Productivity: The large capacity and efficient design enable faster processing times and higher daily output.
- Lower Operating Costs: Enhanced heat efficiency and optional multi-effect/MVR designs lead to significant savings in energy consumption.
- Reduced Downtime: The forced circulation design minimizes scaling, leading to longer operational cycles between cleanings and less maintenance.
- Improved Product Quality: Gentle and controlled evaporation under optimal conditions helps preserve product characteristics and consistency.
- Operational Safety & Reliability: Built with robust components and designed with safety interlocks, ensuring stable and secure long-term operation.
Trust in Qingdao Conqinphi Environmental Technology Group is built on a solid foundation. Established in 2015, we have grown into a significant player with an annual export value ranging between US$10 Million and US$50 Million, serving clients across six continents. Our 201-300 strong team operates from a sizable factory, enabling us to control quality from raw material to finished product. Our adherence to stringent quality management protocols, including ISO 9001 and ISO 14000, underscores our commitment to excellence. Choosing our Large Capacity Forced Circulation Evaporator means partnering with a reliable manufacturer dedicated to providing durable, high-performance equipment that drives efficiency and profitability in your chemical concentration processes. Contact us today to discuss your specific requirements and receive a tailored solution.
Frequently Asked Questions (FAQ):
-
Q: What types of chemical solutions is this evaporator best suited for?
A: It is particularly effective for concentrating viscous fluids, solutions with suspended solids, or those prone to crystallization or scaling, such as inorganic salts, organic compounds, and certain wastewater streams. -
Q: Can the system handle corrosive materials?
A: Yes. While standard construction uses stainless steel, we offer corrosion-resistant materials like SS316L, titanium, or special alloys upon request to match your specific process fluid's properties. -
Q: How is the "large capacity" defined, and can it be customized?
A: Capacity refers to the hourly evaporation rate (e.g., tons of water evaporated per hour). It is fully customizable. We design and scale the heating surface area, pump capacities, and vessel sizes based on your required throughput and feed concentration. -
Q: What are the main energy consumption considerations?
A> The primary energy input is for the heat source (steam/electricity) and the circulation pump. We optimize the design for energy efficiency and can integrate multi-effect or MVR technology to significantly reduce specific energy consumption. -
Q: What level of automation is included?
A: We offer a range from basic manual control to fully automated PLC systems with touchscreen HMIs. Automation can manage start-up, shutdown, parameter monitoring, alarm logging, and data recording for process optimization. -
Q: What is the typical delivery lead time for such a system?
A: Lead time depends on the complexity, size, and customization level. For standard large-capacity designs, it generally ranges from 12 to 20 weeks after finalizing all technical details. We provide a detailed project schedule upon order confirmation. -
Q: Do you provide installation supervision and after-sales support?
A: Yes. We offer comprehensive technical support, including detailed installation manuals, piping & instrumentation diagrams (P&IDs), and optional on-site supervision by our engineers. We also provide operator training and a reliable after-sales service for spare parts and maintenance. -
Q: How does the forced circulation design compare to other evaporator types like falling film or natural circulation?
A> Forced circulation excels where high viscosity or fouling is a concern, as the pumped flow prevents settling. Falling film evaporators are better for heat-sensitive, low-viscosity fluids. Natural circulation units are simpler but have lower heat transfer rates and are not suitable for viscous or scaling feeds.
