Qingdao Conqinphi Environmental Technology Group Co., Ltd. presents the Titanium Forced Circulation Evaporator — a robust solution engineered for chemical concentration processes involving highly corrosive liquids. With over a decade of manufacturing excellence since 2015, our factory spanning 10,000–30,000 square meters employs 201–300 skilled professionals, ensuring every unit meets rigorous quality standards. This evaporator is designed to handle capacities from 0.5 to 5 tons per hour, offering exceptional corrosion resistance and thermal efficiency for demanding industrial applications.
The forced circulation design ensures high heat transfer coefficients and prevents scaling, making it ideal for concentrating acids, alkalis, and salt solutions. Whether you are in the chemical, pharmaceutical, or wastewater treatment industry, this evaporator delivers reliable performance with minimal maintenance. Below we detail the key features, technical specifications, and benefits that set this product apart.
Key Features
Superior Corrosion Resistance: Constructed from high-grade titanium (Gr2/Gr12), the evaporator withstands aggressive chemicals such as sulfuric acid, hydrochloric acid, and caustic soda, extending equipment lifespan.
Forced Circulation Design: A dedicated circulation pump maintains high flow velocity, reducing fouling and scaling, ensuring consistent concentration performance.
Adjustable Capacity: Available in 0.5, 1, 2, 3, 4, and 5 T/H models, with customizable options to match specific production requirements.
Energy Efficient: Utilizes steam or electric heating with optional heat recovery systems, lowering operational costs.
Vacuum Operation: Can operate under vacuum to lower boiling points, ideal for heat-sensitive chemicals.
Compact Footprint: Modular design saves floor space while maintaining easy access for maintenance.
Automation Ready: Equipped with PLC control and touchscreen interface for precise monitoring of temperature, pressure, and flow rate.
Technical Specifications
| Model | CFE-0.5 / CFE-1 / CFE-2 / CFE-3 / CFE-4 / CFE-5 |
| Evaporation Capacity | 0.5 – 5 T/H |
| Material of Construction | Titanium Gr2 / Gr12 (contact parts) |
| Operating Temperature | Up to 150°C (customizable) |
| Operating Pressure | Atmospheric or vacuum (optional) |
| Heating Method | Steam (saturated) or Electric heating |
| Power Supply | 380V / 50Hz, 3-phase (customizable) |
| Control System | PLC + HMI touchscreen |
Advantages & Benefits
Extended Service Life: Titanium construction resists pitting and crevice corrosion, reducing replacement frequency and downtime.
Enhanced Product Quality: Forced circulation prevents localized overheating, maintaining chemical integrity during concentration.
Low Maintenance: Smooth internal surfaces and anti-fouling design simplify cleaning intervals.
Flexible Configuration: Options for single-effect or multi-effect evaporation, with or without thermal vapor recompression (TVR) for energy savings.
Global Compliance: Manufactured under ISO 9001, ISO 14000, and OHSAS 18001 certified management systems (certifications available upon request).
Qingdao Conqinphi has successfully exported to markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania, with annual export values exceeding US$10 million. Our team of 201–300 employees is dedicated to providing tailored solutions and after-sales support. Every evaporator undergoes strict quality control and hydrostatic testing before shipment from Qingdao port.
Invest in the Titanium Forced Circulation Evaporator to achieve reliable, efficient concentration of your most corrosive liquids. Contact us today for a customized quotation or technical consultation. Our engineers are ready to assist with sizing, layout, and integration into your existing process.
Frequently Asked Questions (FAQ)
Q1: What types of corrosive liquids can this evaporator handle?
A: It is suitable for a wide range of acids (sulfuric, hydrochloric, nitric), alkalis (sodium hydroxide), and salt solutions. Titanium is particularly resistant to chlorides and oxidizing acids.
Q2: Can the evaporator operate under vacuum?
A: Yes, vacuum operation is available as an option. It allows lower boiling temperatures, beneficial for heat-sensitive chemicals.
Q3: What is the typical lifespan of the titanium evaporator?
A: With proper maintenance, the titanium components can last 10–15 years, depending on the chemical environment and operating conditions.
Q4: Do you provide installation and commissioning support?
A: Yes, we offer on-site supervision and training for your team. Remote technical support is also available.
Q5: How do I choose the right capacity (0.5–5 T/H) for my process?
A: Our engineers can calculate based on your feed concentration, required final concentration, and available heat source. Contact us with your process parameters.
Q6: Is the evaporator customizable for multi-effect operation?
A: Absolutely. We can design multi-effect or MVR (mechanical vapor recompression) configurations to maximize energy efficiency.
Q7: What certifications does your company hold?
A: Our facility is certified under ISO 9001, ISO 14000, OHSAS 18001, and other management systems. Copies can be provided upon request.
Q8: What is the lead time for delivery?
A: Typical lead time is 30–45 days after order confirmation, depending on specifications and order volume.
