As a leading manufacturer specializing in advanced process equipment, Qingdao Conqinphi Environmental Technology Group is proud to introduce our high-efficiency Compact Forced Circulation Evaporator with an integrated CIP Cleaning System. Designed for industries where space optimization, operational efficiency, and stringent hygiene are paramount, this system represents our commitment to delivering robust, reliable, and smart solutions for concentration and evaporation needs. With over eight years of expertise and a modern manufacturing facility spanning over 10,000 square meters, we engineer each evaporator to meet the rigorous demands of global markets, from North America and Europe to Southeast Asia and Oceania.
Our Compact Forced Circulation Evaporator is engineered to tackle the challenges of concentrating heat-sensitive, viscous, or crystallizing products. The forced circulation mechanism, driven by a high-capacity centrifugal pump, ensures rapid and uniform material flow across the heat exchanger, maximizing heat transfer efficiency and preventing scaling or fouling. This design is particularly advantageous for achieving high concentration ratios and maintaining consistent product quality. The integrated Clean-In-Place (CIP) system is a cornerstone of this unit, enabling thorough, automated cleaning and sterilization without disassembly. This feature drastically reduces downtime between batch cycles, enhances operational safety by minimizing manual intervention, and ensures compliance with strict hygiene standards in sectors like food, dairy, pharmaceuticals, and specialty chemicals.
Key Features & Technical Advantages:
- Space-Saving Compact Design: The skid-mounted, modular construction allows for easy installation in facilities with limited floor space, reducing overall project footprint and installation costs.
- Superior Heat Transfer Efficiency: The forced circulation creates high fluid velocity across the heating surface, leading to high heat transfer coefficients and lower steam consumption per unit of water evaporated.
- Automated CIP Cleaning: The built-in CIP system uses programmable sequences for cleaning, rinsing, and sanitizing with various agents (acid, alkali, hot water), ensuring repeatable cleanliness and reducing labor costs.
- Gentle Product Handling: Short residence time in the heating zone and controlled temperature profiles make this evaporator suitable for temperature-sensitive products, helping preserve vitamins, flavors, and active ingredients.
- Robust Construction: Manufactured from corrosion-resistant stainless steel (SS304 or SS316L as required), the equipment ensures long service life and durability even when processing aggressive media.
- Advanced Process Control: The system is typically equipped with a user-friendly PLC and HMI panel, allowing for precise control over parameters like temperature, pressure, flow rate, and density, with options for data logging and remote monitoring.
Technical Specifications Overview:
The table below outlines some common configurations. All specifications can be customized based on client requirements.
| Parameter | Specification / Options |
|---|---|
| Evaporation Capacity | From 500 kg/hr to 10,000 kg/hr water evaporation |
| Heating Surface Area | Customizable, typically 10 m² to 200 m² |
| Operating Pressure | Vacuum operation (customizable pressure range) |
| Final Product Concentration | Up to 60-70% Total Solids (product dependent) |
| CIP System | Multi-tank system with pumps, heaters, and programmable logic |
| Control System | PLC with color touchscreen HMI, optional SCADA integration |
Benefits for Your Operation:
Investing in our Compact Forced Circulation Evaporator translates into tangible benefits for your production line:
- Increased Productivity: Higher evaporation rates and automated CIP reduce batch cycle times, increasing overall throughput.
- Lower Operational Costs: Enhanced thermal efficiency reduces steam/energy consumption, while automated cleaning cuts down on water, chemical, and labor expenses.
- Consistent Product Quality: Precise process control ensures uniform concentration and product characteristics batch after batch.
- Enhanced Safety & Compliance: The closed system and automated CIP minimize operator exposure to chemicals and hot surfaces, supporting workplace safety and meeting international hygiene standards.
- Reduced Maintenance: The robust design and effective CIP minimize scaling and fouling, leading to less frequent maintenance intervals and longer equipment life.
Backed by Conqinphi's strong manufacturing credentials, including a comprehensive quality management system aligned with ISO 9001 standards and annual exports valued between US$10-50 million, you can trust in the reliability and performance of our equipment. Our evaporators are designed and built by a team of over 200 professionals in our expansive facility, ensuring every detail from material selection to final testing meets high standards. Serving a diverse global clientele across six continents, we understand the specific needs of different markets and applications. Choosing our Compact Forced Circulation Evaporator means choosing a partner dedicated to optimizing your concentration process, reducing your total cost of ownership, and supporting your growth with dependable, high-performance technology. Contact us today to discuss your project requirements and receive a tailored solution proposal.
Frequently Asked Questions (FAQ):
-
Q: What are the main advantages of a forced circulation design over a natural circulation evaporator?
A: The forced circulation, driven by a pump, creates much higher fluid velocity across the heating tubes. This results in significantly improved heat transfer coefficients, better handling of viscous or fouling-prone liquids, and higher achievable concentration levels, making it more efficient and versatile for demanding applications. -
Q: How does the integrated CIP system work, and what are its benefits?
A: The CIP system automates the cleaning process using pre-programmed sequences that circulate cleaning solutions (e.g., caustic, acid, hot water) through the entire evaporator circuit without disassembly. Benefits include consistent cleaning results, major reductions in downtime and labor, improved hygiene, and enhanced operational safety. -
Q: Is this evaporator suitable for my heat-sensitive product (like fruit juice or enzymes)?
A: Yes, it is well-suited. Operating under vacuum lowers the boiling point, and the forced circulation design minimizes product residence time in the heater, both of which help protect heat-labile components, preserving quality attributes like color, flavor, and nutritional value. -
Q: Can the system be customized for my specific capacity and space constraints?
A: Absolutely. As a manufacturer, we specialize in custom engineering. The "compact" and skid-mounted design is inherently flexible. We can tailor the evaporation capacity, heating surface, material of construction (e.g., SS316L for corrosive fluids), and control system to match your exact production rate and factory layout. -
Q: What kind of after-sales support and services do you provide?
A: We offer comprehensive support including detailed installation guidance, operator training, technical documentation, and readily available spare parts. Our service team can provide remote assistance and, if needed, on-site support to ensure optimal long-term performance. -
Q: What heating sources are compatible with this evaporator?
A: The system is typically designed for steam as the primary heating medium, but it can also be configured for thermal oil or other heat transfer fluids based on your plant's available utilities and specific process temperature requirements. -
Q: How energy-efficient is this evaporator compared to other types?
A: Forced circulation evaporators are recognized for their good energy efficiency, especially when configured with features like thermal vapor recompression (TVR) or mechanical vapor recompression (MVR), which can be integrated to significantly reduce steam consumption. The high heat transfer efficiency inherently lowers energy use per unit of product. -
Q: What industries typically use this type of evaporator?
A: It is widely used in the food and beverage industry (for milk, whey, juice, sugar), pharmaceutical and biotechnology sectors (for antibiotic broth, extracts), chemical industry (for salt, NaOH, organic solutions), and environmental applications (for wastewater concentration).
