Product Overview
The MAC liquid valve series benefits from many of the same innovative features and associated advantages that have come to define MAC’s performance over the years. Fast response times, reliable actuation force, and repeatable results are just some of the benefits you can expect from our fluid product line. Proportional Flow Control (PFC), flow straight-through valves, single-diaphragm and double-diaphragm (media-separated) valves, wet solenoid valves, and dispensing pumps are just a few of the products in the MAC Liquid Valve Series. These valves also perform well in pneumatic applications that require sealing performance. The MAC Liquid Valve Series is designed for a longer service life and superior performance in harsh applications. With fewer wear points than traditional valve technologies, these valves are built to last!
| Technical Parameter | Specification |
|---|---|
| Origin | USA |
| Configuration | 2-way & 3-way, radial and axial flow |
| Solenoid Arrangement | Wetted or non-wetted |
| Pressure Range | 0 to 120 PSI |
| Power | 1.8 to 16 W |
| Air Flow | Up to 0.4 Cv |
| Liquid Flow | 0 to 3.0 G/min |
| Flow Rate | µL per pulse, Max 4 GPM |
| Compatible Fluids | Compressed air, vacuum, gas, liquid |
| Voltage Options | 5 VDC, 12 VDC, 24 VDC |
| Valve Body Material | Nickel-plated brass, stainless steel, plastics (various grades & types) |
| Elastomer Material | FKM, FFKM, NBR, HSN, HNBR, multiple versions meeting FDA/NSF standards |
| Manifold Configuration | Single station and custom manifold design |
Performance Features
2-way, 3-way, variable flow, filling, and metering valves
Wet and dry (medium-separated) solenoid valves
Accurate and repeatable dosing
Dual-diaphragm D-Flex technology
Reliable operation in harsh environments
Longer service life and superior performance
Fewer wear points than traditional valve technologies
Quiet operation
Highly customizable
Smaller footprint, higher flow rates
Product Applications
Printing – Ink, Test Equipment – Gas, Food and Beverage – Water/CO₂, Agriculture – Water/Fertilizer
