Product Description
This coal dryer flow diagram with equipment list is a complete set of professional technical supporting materials tailored for industrial coal drying projects. It visually presents the full flow direction of materials, hot air and tail gas in the drying system through the process diagram, and matches the detailed parameter list of all supporting equipment. It can be directly used for project scheme demonstration, on-site installation guidance and equipment procurement reference, and is widely applicable to coal washing plants, power plants, coal slime treatment bases and other scenarios.
Working Principle
The full process of the coal drying system follows the logic of "feeding → heat exchange drying → dust removal purification → finished product output":
The wet coal is evenly sent to the dryer main unit through the feeding system, and fully contacts with hot air in the rotary drum for heat exchange to evaporate excess moisture.
The evaporated water vapor and dust are sent to the multi-stage dust removal system for purification, and then discharged up to the environmental protection standard.
The dried low-moisture coal is continuously output through the finished product conveying system. The flow diagram clearly marks the connection sequence of each link, and the equipment list covers all core and auxiliary units of the whole system.
Key Features
The process diagram is clear and intuitive, accurately marking the flow direction of each medium and the layout position of equipment.
The equipment list contains complete parameters, models and configuration descriptions, which can be directly used for procurement bidding.
Customizable for different coal types (raw coal, coal slime, lignite, etc.) and different processing capacities.
Strictly comply with industrial safety and environmental protection specifications, no unreasonable process design.
The content is highly compatible with mainstream coal dryer systems on the market, with strong practical operability.
Technical Specifications
| Model | Reducer Model | Speed（r/min） | Motor power（kw） | Weight（t） |
| φ1.2×3 | ZQ350 | 10-15 | 4 | 2 |
| φ1.5×4 | ZQ350 | 10-15 | 5.5 | 3 |
| φ1.8×5 | ZQ400 | 10-15 | 7.5 | 4 |
| φ2.0×5 | ZQ400 | 10-15 | 7.5 |
5 |
