Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a trusted manufacturer with over 8 years of expertise in industrial evaporation solutions. Our Horizontal Flow MVR Evaporator is engineered to deliver maximum energy efficiency and reliability, backed by a 3-year warranty and a comprehensive Mill Test Report for every unit shipped. This system utilizes mechanical vapor recompression technology to drastically reduce operating costs while achieving high concentration ratios, making it an ideal choice for wastewater treatment, chemical processing, and food industry applications.
With a factory spanning 10,000–30,000 square meters and an annual export value of US$10–50 million, we serve clients across North America, Europe, Asia, Africa, and Oceania. Our Horizontal Flow MVR Evaporator is built to withstand harsh conditions and deliver consistent performance, with all critical components sourced from reputable suppliers. The included Mill Test Report provides verified material and performance data, ensuring your investment meets the highest standards.
Key Features & Technical Specifications
- Energy-Efficient MVR Technology: Recovers latent heat from vapor, achieving up to 90% energy savings compared to traditional multi-effect evaporators.
- Horizontal Flow Design: Provides uniform heat transfer, reduced fouling, and easy maintenance; ideal for high-viscosity or scaling-prone liquids.
- 3-Year Warranty: Covers manufacturing defects and performance issues, giving you peace of mind for long-term operation.
- Mill Test Report Included: Detailed documentation of material composition, weld integrity, pressure test results, and dimensional checks.
- Flexible Capacity: Standard models range from 1 ton/h to 50 ton/h evaporation rate, with custom sizes available upon request.
- Robust Construction: Made from stainless steel 304 or 316L (customizable) to resist corrosion and extend service life.
- Automated Control System: PLC-based control with touchscreen interface for real-time monitoring of temperature, pressure, and flow rate.
- Low Maintenance: Self-cleaning design options and easy access to heat exchange surfaces reduce downtime.
| Parameter | Standard Specification |
|---|---|
| Evaporation Capacity | 1 – 50 t/h (customizable) |
| Operating Temperature | 50°C – 120°C |
| Compressor Type | Centrifugal or Roots blower (depending on model) |
| Power Consumption | 20 – 60 kWh/ton of water evaporated |
| Material of Construction | SS304 / SS316L / Duplex (optional) |
| Warranty | 3 years |
| Control System | PLC + HMI touchscreen |
| Power Supply | 380V/440V/690V, 50/60Hz (as specified) |
Why choose our Horizontal Flow MVR Evaporator? The horizontal arrangement minimizes floor space and allows gravity-assisted drainage, reducing pumping energy. The MVR compressor recycles the vapor generated, cutting steam consumption by over 90%. This results in lower operating costs and faster payback — typically within 1–2 years for high-volume applications.
Trust & Quality Assurance
As a manufacturer established in 2015 with 201–300 employees, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has delivered systems to international clients including those in North America, Europe, Southeast Asia, and Africa. Our facility is certified under ISO9001, ISO14000, HACCP, SA8000, OHSAS18001, and many other standards, reflecting our commitment to quality and social responsibility.
Every Horizontal Flow MVR Evaporator undergoes rigorous testing before shipment. The Mill Test Report includes material certificates, pressure test records, dimensional verification, and performance curves. Combined with our 3-year warranty, you can be confident in reliable operation for years to come.
Contact us today for a customized solution. Whether you need a standard unit or a tailor-made system for your specific effluent, our engineering team is ready to assist. We offer comprehensive after-sales support including installation guidance, commissioning, and remote troubleshooting. Choose Qingdao Conqinphi — choose long-term partnership.
Frequently Asked Questions (FAQ)
Q1: What does MVR stand for and how does it work?
A: MVR stands for Mechanical Vapor Recompression. It compresses the vapor produced during evaporation to increase its temperature and pressure, then reuses that vapor as the heating medium. This significantly reduces the need for fresh steam or other heat sources.
Q2: What are the advantages of a horizontal flow design compared to vertical?
A: Horizontal flow evaporators offer easier access for cleaning, longer heat transfer tubes, and better handling of scaling or viscous liquids. They also have a lower profile, making them suitable for installations with height restrictions.
Q3: What does the Mill Test Report include?
A: The Mill Test Report provides documented proof of material quality (e.g., chemical composition, mechanical properties), weld inspection results, hydrostatic pressure test data, and overall dimensional conformity. It ensures full traceability and compliance with engineering standards.
Q4: Is the 3-year warranty valid internationally?
A: Yes, our standard 3-year warranty covers manufacturing defects and performance for all international customers. Specific terms may be adjusted based on local regulations, but we consistently offer strong after-sales support worldwide.
Q5: Can the evaporator handle high-concentration or crystallizing solutions?
A: Yes, the horizontal flow design can be configured with forced circulation or a scraped surface heat exchanger to handle crystallization. We can customize the system for your specific fluid properties.
Q6: What is the typical payback period for an MVR evaporator?
A: In most industrial applications with high evaporation loads, the payback period ranges from 1 to 3 years due to drastically reduced energy and steam costs. For example, replacing a three-effect evaporator with an MVR can cut energy costs by 60–80%.
Q7: Do you provide installation and commissioning support?
A: Absolutely. Our team can offer on-site supervision (or remote guidance) during installation and commissioning. We also provide training for operators and a comprehensive operation manual.
Q8: How do I select the right capacity for my facility?
A: Please provide your feed flow rate, initial concentration, target concentration, and operating temperature range. Our engineering team will run simulations and recommend the optimal model. We also offer pilot testing service to verify performance.
