Qingdao Conqinphi Environmental Technology Group Co., Ltd. presents our advanced Horizontal Flow MVR Evaporator, constructed from high-grade Stainless Steel 304 and equipped with a sophisticated PLC Control System operating at 60Hz. As a specialized manufacturer since 2015, we have delivered reliable evaporation solutions to clients across North America, South America, Europe, Asia, and beyond, with annual exports exceeding US$10 million. This evaporator is designed to maximize energy efficiency through mechanical vapor recompression (MVR) technology, significantly reducing operational costs while ensuring consistent, high-purity output.
Product Overview
The Horizontal Flow MVR Evaporator utilizes a horizontal tube bundle configuration that optimizes heat transfer and minimizes fouling. The 304 stainless steel construction offers excellent corrosion resistance, making it suitable for a wide range of liquids including saline solutions, industrial wastewater, and food processing concentrates. The integrated PLC control provides precise automation of temperature, pressure, flow rates, and level, enabling unattended operation and real-time data logging.
| Parameter | Specification |
| Material | Stainless Steel 304 (optional SS316L) |
| Evaporator Type | Horizontal Flow, MVR (Mechanical Vapor Recompression) |
| Control System | PLC (Programmable Logic Controller) with HMI |
| Power Supply | 60Hz, 3-Phase, 380V/480V (customizable) |
| Compression Ratio | 1.5 – 2.0 (adjustable) |
| Evaporation Temperature | 40°C – 100°C (depending on application) |
| Capacity Range | 20 – 500 tons/day (customizable) |
| Certifications | ISO9001, ISO14000, OHSAS18001, HACCP, QS9000, etc. |
| Warranty | 12 months standard (extended available) |
Key Features & Benefits
- Energy Efficiency: MVR technology reuses vapor compression, consuming only 1/3 to 1/2 the energy of traditional multi-effect evaporators.
- Horizontal Design: Reduces scaling and fouling, permits easier cleaning and maintenance, and improves heat transfer coefficient.
- 304 Stainless Steel: Excellent resistance to corrosion and oxidation, ideal for acidic, alkaline, and chloride-containing media.
- PLC Automation: Touch-screen interface allows real-time monitoring of temperature, pressure, flow, and concentration; supports remote control and data export (Modbus/OPC optional).
- 60Hz Operation: Built for North American and other 60Hz power grids; motors and compressors are optimized for stable performance.
- Compact Footprint: Horizontal layout reduces height requirements, making installation easier in existing facilities.
- Versatile Applications: Suitable for brine concentration, zero liquid discharge (ZLD), food extract concentration, and chemical recovery.
- Low Maintenance: Smooth tube surfaces and anti-scaling coatings (optional) extend cleaning intervals.
Technical Advantages
Our Horizontal Flow MVR Evaporator incorporates a centrifugal compressor with variable speed drive (optional) to match the exact compression demand. The separation chamber is designed to minimize liquid carryover, ensuring high-purity distillate. The entire system is pre-assembled on a skid, drastically reducing field installation time. All wetted parts are 304 SS, and gaskets are PTFE or EPDM, compatible with most process fluids.
Trust & Reliability
Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a factory spanning 10,000-30,000 square meters with 201-300 skilled employees. We hold multiple management system certifications including ISO9001, ISO14000, OHSAS18001, HACCP, QS9000, SA8000, and more. With an annual export value between US$10-50 million, our evaporators have been delivered to over 20 countries. Every unit undergoes rigorous testing prior to shipment. Our after-sales support includes remote troubleshooting, spare parts supply, and on-site commissioning assistance.
Frequently Asked Questions
Standard capacity ranges from 20 to 500 tons per day. Custom designs are available for larger or smaller flows. Please provide your feed concentration, required concentration, and flow rate for a tailored solution.
Yes, the 304 stainless steel construction is resistant to chloride stress corrosion up to moderate concentrations. For high chloride (e.g., >3000 ppm) or acidic conditions, we recommend SS316L or duplex options.
Yes, the HMI supports multi-language interfaces (English, Spanish, Chinese, etc.). Custom programming for specific control sequences can be arranged.
Periodic inspection of compressor oil, seals, and tube surfaces is recommended. Cleaning frequency depends on scaling tendency; automatic CIP (clean-in-place) system can be integrated.
The standard model is designed for 60Hz. A 50Hz version with different motor and compressor is available upon request. Please specify your local power supply.
We have ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, QS9000, and others. Specific certifications such as ASME or CE can be arranged at an additional cost.
Standard warranty is 12 months from commissioning. Extended warranties up to 36 months are available as an option.
Yes, our engineers can supervise on-site installation and start-up. Remote guidance via video call is also supported.
Contact us today for a customized quotation and technical proposal. Let our expertise in MVR evaporation help you achieve sustainable, cost-effective liquid concentration.
