Help CenterStainless Steel MVR Integrated Skid Equipment, 316L, Heat Pump Type, 0.8 MPa Operating Pressure
Product Spotlights
Related Products
-
High-Efficiency MVR Skid-Mounted Evaporator, 15kW Motor, 2-Stage Compression, CE-Approved DesignUS$ 2700 - 76300MOQ: 1 Combo -
MVR Integrated Skid-Mounted Evaporator, 10 T/H Capacity With PLC Automatic Control, 304 SS ConstructionUS$ 2700 - 76300MOQ: 1 Combo
-
Modular MVR Skid Equipment, 1000L/h Evaporation Rate, ≤100°C Operating Temp, Touch Screen HMIUS$ 2700 - 76300MOQ: 1 Combo
-
Compact MVR Skid-Mounted Unit, 220V/380V, 50Hz, Energy-Saving Evaporation System for 5-20 T/DUS$ 2700 - 76300MOQ: 1 Combo
-
MVR Skid-Mounted Evaporator for Wastewater Treatment, Zero Liquid Discharge in Chemical PlantsUS$ 2700 - 76300MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. is a professional manufacturer with over 200 experienced employees and a factory size of 10,000-30,000 square meters. Our Stainless Steel MVR Integrated Skid Equipment (316L, Heat Pump Type, 0.8 MPa Operating Pressure) represents a breakthrough in energy-efficient evaporation and concentration solutions. Designed for demanding industrial environments, this equipment combines advanced mechanical vapor recompression (MVR) technology with a compact skid-mounted layout, significantly reducing installation costs and footprint. With annual export values exceeding US$10 million, our products are trusted across North America, Europe, Southeast Asia, and beyond.
This MVR integrated skid unit is constructed entirely of 316L stainless steel, offering superior corrosion resistance against chlorides, acids, and alkalies commonly found in industrial wastewater. The heat pump type design leverages a vapor compressor to recycle latent heat, achieving energy savings of up to 60% compared to traditional multi-effect evaporators. Operating at a stable 0.8 MPa pressure, the equipment ensures efficient heat transfer and consistent concentration rates. Key technical features include:
- High Efficiency Compressor: Oil-free or semi-hermetic screw compressor with variable frequency drive for precise pressure control.
- Intelligent Control System: PLC + HMI touchscreen for automated operation, real-time monitoring, and remote diagnostics.
- Modular Skid Design: Pre-assembled and tested before shipment, minimizing on-site installation time.
- Customizable Capacity: From 1 T/H to 50 T/H evaporation rate, tailored to client-specific feed composition and target concentration.
| Parameter | Specification |
|---|---|
| Material of Construction | 316L Stainless Steel (contact parts); Carbon steel frame optional |
| Operating Pressure | 0.8 MPa (customizable up to 1.2 MPa upon request) |
| Compressor Type | Heat pump type (screw or centrifugal, depending on capacity) |
| Evaporation Temperature | 55–100°C (adjustable) |
| Power Consumption | ~0.3–0.6 kWh per ton of water evaporated (depending on feed) |
Our MVR skid equipment offers distinct customer benefits:
- Reduced Energy Costs: Heat pump technology recovers compression heat, dramatically lowering steam consumption.
- Long Service Life: 316L material withstands corrosive media, reducing maintenance frequency.
- Faster Payback: Typical ROI within 12–24 months based on energy savings.
- Environmental Compliance: Closed-loop design minimizes vapor emissions; condensate can be recycled for reuse.
As a manufacturer with over 9 years of experience and certifications including ISO9001, ISO14001, and OHSAS18001, Qingdao Conqinphi ensures every unit undergoes rigorous quality testing. Our factory of 10,000–30,000 m² houses advanced fabrication and a fully equipped pilot lab for on-site performance validation. With annual export value of US$10–50 million, we serve clients across 20+ countries and regions, including demanding markets in Europe and North America. We offer comprehensive after-sales support, including installation guidance, commissioning, and remote troubleshooting. Contact us today to discuss your specific evaporation requirements and receive a customized proposal.
Frequently Asked Questions (FAQ)
Q1: What industries are suitable for this MVR skid equipment?
A: It is widely used in chemical, pharmaceutical, food & beverage, dairy, desalination, and industrial wastewater treatment for concentrating solutions or recovering solvents.
Q2: Can the equipment handle high-viscosity fluids or those containing solids?
A: Yes, we can incorporate forced circulation or scraper mechanisms for viscous or fouling media. Please provide detailed feed characteristics for customization.
Q3: How long does delivery typically take?
A: Standard lead time is 45–60 days after order confirmation. Customized units may require 60–90 days depending on complexity.
Q4: Is the skid unit pre-tested before shipping?
A: Absolutely. Each unit undergoes full assembly, hydrostatic testing, and functional testing in our factory. We also offer witnessed testing if requested.
Q5: What is the required utility supply for operation?
A: Main utilities include electricity (380V/50Hz or custom), cooling water (if needed for condenser), and compressed air for control valves. Specific data will be provided in the technical datasheet.
Q6: Can the operating pressure be adjusted other than 0.8 MPa?
A: Yes, we design for pressures from 0.2 MPa up to 1.2 MPa. Different pressure levels affect evaporation temperature and energy efficiency; our engineers will recommend the optimal value.
Q7: Do you provide warranty and spare parts?
A: Standard warranty is 12 months from commissioning. Spare parts (e.g., seals, gaskets, compressor parts) are available from our stock. Extended warranty options are negotiable.
Q8: What makes this unit more energy-efficient than traditional evaporators?
A: The heat pump MVR reuses the latent heat of vapor by compressing the vapor to a higher temperature, requiring only electrical input for the compressor. This reduces steam demand by 70–90% compared to single-effect evaporation.
