Deqing Leixin Coating Equipment Co., Ltd. specializes in manufacturing advanced painting and powder coating systems for the automotive industry. Since 2011, we have been delivering reliable, high-efficiency painting lines designed for sheet metal parts such as auto wheel rims. Our Wheel Rim Paint Painting Line with Powder Coating Spray Booth is engineered to meet the demands of medium to high-volume production, offering consistent quality, minimal waste, and outstanding surface finish. With over a decade of experience, we integrate ISO9001-certified processes into every system we build, ensuring that your investment yields long-term productivity gains.
This painting line is particularly suited for auto parts manufacturers who need a complete, turnkey solution from pretreatment to curing. The system includes a powder coating spray booth with advanced dust collection, a conveyor system, and a curing oven. Whether you are coating steel wheel rims, aluminum rims, or other sheet metal components, our line provides uniform film thickness, excellent adhesion, and a durable finish that resists chipping and corrosion. Below we break down the key features and technical specifications.
Key Features & Technical Specifications
Modular Spray Booth Design – Down-draft or side-draft configuration available, with stainless steel walls for easy cleaning and corrosion resistance. Equipped with high-efficiency cartridge filters (99.9% removal rate).
Powder Coating System – Includes automatic electrostatic powder guns (optional manual touch-up stations) for consistent coverage. Gun reciprocating mechanism ensures uniform coating on complex rim geometries.
Conveyor System – Overhead or floor-mounted chain conveyor with variable speed drive. Workpiece hangers are adjustable for different rim sizes (12" to 24" typical).
Curing Oven – Hot air circulation oven with multi-zone temperature control (range: 100°C–250°C). Infrared heating modules optional for rapid curing cycles.
Pretreatment Section – Optional spray washer with degreasing, rinsing, and phosphating stages for optimal adhesion. Can be integrated as a prepackage module.
Control System – PLC-based with HMI touch screen. Real-time monitoring of temperature, conveyor speed, powder flow, and filter status. Data logging for quality traceability.
Safety & Compliance – Explosion-proof electrical components, emergency stop buttons, and interlocking doors. Meets CE standards (optional upon request).
Customization – Line width, oven length, number of spray booths, and color can be customized to fit your existing workshop layout.
| Parameter | Typical Value / Options |
|---|---|
| Production Speed | 1–6 meters/min (adjustable) |
| Max Workpiece Size | Diameter 600 mm, height 350 mm (customizable) |
| Coating Efficiency | ≥ 85% (first pass, with reclaim) |
| Curing Temperature Uniformity | ± 3°C across oven |
| Power Supply | 380V/50Hz or 480V/60Hz (custom) |
| Air Consumption | 6–8 bar, 1.5 m³/min |
| Booth Dimension (L x W x H) | 8m x 3m x 3m (standard, customizable) |
Beyond the core specifications, our painting line offers tangible benefits for your production floor. Key advantages include:
Reduced overspray – The powder booth’s optimized airflow captures over 99% of excess powder, which is recycled back to the feed system, saving material costs up to 30%.
Consistent finish – Automatic gun movement and closed-loop control deliver uniform coating thickness (typically 60–120 µm), eliminating rejects caused by uneven spray.
Energy efficiency – The curing oven is heavily insulated with rock wool panels, and the recirculating air system reduces heat loss. Estimated energy savings of 15–20% compared to conventional ovens.
Quick changeover – Color change can be performed in under 15 minutes using a dedicated powder recovery and cleaning system (optional color-change booth available).
Low maintenance – The conveyor chain is self-lubricating, and the booth walls are treated for easy powder cleaning. Filters can be replaced in minutes without tools.
At Deqing Leixin Coating Equipment Co., Ltd., we bring reliability and experience to every project. Our factory in Huzhou, Zhejiang spans 1,000–3,000 square meters and houses a team of 51–100 skilled professionals. We have successfully exported painting lines to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, East Asia, and Western Europe, with an annual export value of US$1 Million – US$1.5 Million. Every system is manufactured under strict ISO9001 quality management procedures, ensuring that your wheel rim painting line meets international standards. Our dedicated after-sales team provides remote technical support, on-site installation guidance, and spare parts availability. We are committed to helping you achieve a smooth production ramp-up and long-term operational excellence.
Why choose Deqing Leixin? We are a manufacturer, not a trader, which means you get direct factory pricing and full customization control. With a proven track record in the auto parts coating industry, we understand the specific challenges of painting wheel rims: sharp edges, deep recesses, and high aesthetic requirements. Our line addresses these with precision. Contact us today to discuss your project requirements and request a detailed proposal and reference list.
Frequently Asked Questions
Q: What types of wheel rims can your painting line handle?
A: Our line is designed for steel and aluminum wheel rims typically used in passenger cars, SUVs, and light trucks. It can accommodate rims up to 24 inches in diameter. Custom tooling is available for larger or non-standard sizes.Q: Do you provide installation and training?
A: Yes, we offer on-site installation supervision and training for your operators and maintenance staff. Remote support via video call is also available during commissioning.Q: What is the typical delivery lead time?
A: Standard lead time is 45–60 days after order confirmation and down payment, depending on customization complexity. We will provide a precise schedule during the quotation phase.Q: Can the line be used for both powder coating and liquid painting?
A: The standard configuration is dedicated to powder coating. If you need a hybrid line for both powder and liquid, we can design a modified booth with explosion-proof ventilation and optional liquid spray equipment. This requires a separate consultation.Q: How do you ensure the coating quality meets automotive standards?
A: Our line includes automatic parameters control and real-time monitoring. We also recommend including a test coupon rack in the oven for periodic adhesion and thickness tests. Many of our clients pass OEM audits without issues.Q: What is your warranty policy?
A: We provide a 12-month warranty from the date of commissioning, covering manufacturing defects in materials and workmanship. Spare parts are available for prompt replacement.Q: Can you customize the line for a limited production space?
A: Absolutely. Our engineers can adapt the layout to fit existing workshops, including L-shaped or U-shaped configurations. We will perform a site survey remotely or in person to design the optimal solution.Q: Do you offer financing or payment terms?
A: Standard payment terms are 30% TT deposit, 70% TT before shipment (or LC at sight). For large projects, we may discuss progress billing. Please contact our sales team for details.
For more information or a tailored quotation, please reach out to us at Deqing Leixin Coating Equipment Co., Ltd. We look forward to assisting you with your automotive painting needs.
